Schneider Electric Front element
Colour15
Product details
Schneider Electric Front Element ZB4BK1583
Manufacturer: Schneider Electric
Designation: Front Element ZB4 yellow 3 Position
Type: ZB4BK1583
Number of Switching Positions: 3
Actuator Type: Rotary Knob
Suitable for Lighting: yes
Color of Actuator: yellow
Color of Indicator Light Dome: yellow
Lens Shape: round
Hole Diameter: 22.5 mm
Push Button: yes
With Front Ring: yes
Material of Front Ring: Metal
Color of Front Ring: other
Protection Class (IP), front side: IP66
Protection Class (NEMA): other
Schneider Electric Front Element ZB4BK1583: additional details
Front element for Harmony XB5 illuminated selector switch. With 3 positions, center latching, left and right momentary. Installation size 22 mm diameter. Protection class up to IP69K. Color yellow. This illuminated push button for integrated LED provides a versatile interface for controlling your machines. The illuminated head and clear colors make it easily visible from a distance.
Colour | Yellow |
Mounting type | Built-in installation |
Diameter | 22.50 mm |
Item number | 34991362 |
Manufacturer | Schneider Electric |
Category | Buttons + Switches |
Manufacturer no. | ZB4BK1583 |
Release date | 17.5.2023 |
External links |
Colour | Yellow |
Exact colour description | Other, Yellow |
Material group | Metal |
Material | Metal |
Operating mode | Rotary knob |
Number of actuation levels | 3x |
Mounting type | Built-in installation |
LED colour | Yellow |
Protection type (IP code) | IP66 |
Switch + push-button Additional function | Lighting |
Country of origin | France |
Manufacturer commitment | RE100, SBTi |
CO₂ emissions | 95.84 kg |
Climate contribution | CHF 1.55 |
Items per sales unit | 1 pcs. |
Scope of delivery | Front element ZB4BK1583 |
Diameter | 22.50 mm |
