Voltima Genio GSM200-36

200 W, 11 kg
Currently out of stock

Product details

Solar modules from the Voltima GSM series Solar modules from the Voltima GSM series convert sunlight in a particularly energy-efficient way thanks to their monocrystalline silicon cells. Environmentally conscious energy consumers get the latest solar cell technology with the GSM series from Voltima. By the way, the abbreviation "GSM" stands for "Genio Shingle Solar Panel", whereby "shingle" is the English word for "shingle". Why Shingle technology? They are among the best-structured, most sophisticated solar panels currently available: Solar modules with shingle technology. In conventional solar modules, continuous copper ties interconnect the individual cells - hence "cell connectors". In addition, main conductor tracks (busbars) run through the panels. Solar modules with shingle technology are different. Instead of individual cells, they use narrow cell strips, which makes cell connectors superfluous. In solar modules, an extremely conductive special adhesive with integrated metal particles connects the individual, slightly overlapping cell strips.

Key specifications

Length
110 cm
Width
89 cm
Cell type
Monocrystalline
Nominal power
200 W
Solar panel type
Solar panel
Item number
25164211

General information

Manufacturer
Voltima
Category
Solar panels
Manufacturer no.
GSM200-36
Release date
14.4.2023

Solar Technology properties

Solar panel type
Solar panel
Socket type
MC4
Protection type (IP code)
IP67

Solar panel properties

Cell type
Monocrystalline
Solar panel design
Rigid
Nominal power
200 W
Rated current (MPP)
10.70 A

Voluntary climate contribution

CO₂-Emission
Climate contribution

Product dimensions

Length
110 cm
Width
89 cm
Height
3 cm
Weight
11 kg

Package dimensions

Length
113 cm
Width
90 cm
Height
4 cm
Weight
11 kg
