Victron Energy MultiPlus-II 48/6k5/100-32 230V GX

MultiPlus-II GX

Inverter/Charger with Integrated GX Unit

As the name suggests, the MultiPlus is a combination of an inverter and a charger. This elegant solution offers numerous features typical of a true sine wave inverter, an adaptive charging function, hybrid PowerAssist technology, and multiple options for system integration. As an inverter/charger with integrated device networking, the MultiPlus-II GX communicates with a solar charger, batteries, and other devices to manage grid-connected, off-grid, or remote power installations. The MultiPlus-II GX can operate in parallel to increase power output or battery charging capacity and can also be configured for three-phase power supply. A variety of advanced features, such as uninterruptible power supply, setting load limits, and supplementing limited grid power availability with battery power, can be controlled directly from a smartphone. Remote monitoring is also possible.

Models:
3000VA, 5000VA, 4kW, 6kW

GX Device / Module
The integrated GX device includes:
• A BMS-Can interface. This can be used to connect to a compatible battery managed via the CAN bus. Note that this is not a VE.Can compatible connection.
• A USB port
• An Ethernet port
• A VE.Direct port

The GX device controls the MultiPlus-II and the SmartSolar MPPT, each with a VE.Bus and a VE.Direct connection.

How is the GX module connected to the internet and linked to the VRM portal, and what settings are required?.
