Vertiv GXT5 6000

6000 VA, 6000 W, Online double converter UPS
Ratings
Delivered between Fri, 26.9. and Wed, 1.10.
Only 1 piece in stock at supplier
free shipping

Product details

This single-phase UPS operates with high energy efficiency and is ideally suited to protect critical infrastructures in both centralized and edge applications of networks. The connection and commissioning of a UPS with more than 3.5 kVA must be clarified in advance with the local electricity provider. The connection must be carried out by an electrician.

Key specifications

Operating time at full load
5.50 min
Model
Desktop
Scope of application
Server room, Workplace + home use
Plug type
C13, C19
Item number
12319723

General information

Manufacturer
Vertiv
Category
UPS
Manufacturer no.
GXT5-6000IRT5UXLE
Release date
14.11.2019

UPS properties

UPS type
Online double converter UPS
Power output
6000 W
Output power capacity
6000 VA
Model
Desktop
Rack Unit
5U
shaft type
Sine wave

UPS functions

UPS protection functions
Overvoltage protection

Application range

Scope of application
Server room, Workplace + home use

Connector plug

Plug type
C13, C19

Connections

Connections
USB
Data ports
RS-232 (1x)

Mains supply properties

input voltage
176 - 288 V
output voltage
230 V
Input frequency
50 - 60 Hz
Output frequency
50 - 60 Hz
Efficiency battery operation
94 %

Operating conditions

Maximum operating temperature
40 °C
Operating temperature
0 - 40 °C
Operating humidity
0 - 95%
Max. noise level
55 dB
Protection type (IP code)
IP20

Battery properties

Battery category
Industry battery
Battery
Battery
Battery type
Lead–acid battery
Battery size
Device specific
Number of cells
16 x
Battery weight per cell
2700 g
Voltage
12 V
Capacity
9 Ah
Charging time
5 h
Operating time at full load
5.50 min
Operating time at half load
14.50 min

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
USB cable
Items per sales unit
1 x

Product dimensions

Height
217 mm
Weight
70.80 kg
Width
430 mm
Length
630 mm

Package dimensions

Length
80 cm
Width
62 cm
Height
52 cm
Weight
86 kg

30-day right of return
24 Months Warranty (Bring-in)
