Turck Actuator and sensor cable PP-EPDM connection cable RKCV4.5T-2/TFW

2 m
Ratings
Delivered between Fri, 19.9. and Thu, 9.10.
Free shipping starting at 50.–

Product details

Turck actuator and sensor cable RKCV4.5T-2/TFW Manufacturer :Turck Designation :Actuator and sensor cable PP-EPDM Type :RKCV4.5T-2/TFW Number of poles :5 Version of electrical connection, housing side :M12 Type of plug contact, housing side :female Cable feed arrangement, housing side :straight Cable length :2 m Material of cable sheath :other Colour of cable sheath :white With LED indicator :no Shielded :no Cable type :multi-core Material of contact base :CuZn Material of contact coating :gold Perm. Permissible external cable temperature after assembly without vibration :-40..105 °C Permissible external cable temperature during installation/handling :0..80 °C Rated current In :4 A Rated voltage :60 V Turck actuator and sensor cable RKCV4.5T-2/TFW: more details Actuator and sensor cable / PP-EPDM, connection cable, M12 coupling, straight, 5-pin, union nut/screw in stainless steel, sheath material: PP-EPDM, sheath colour: White, Resistant to acids and alkalis, Resistant to cleaning agents and disinfectants, Hydrolysis-resistant in accordance with DIN EN 60068-2-78, Silicone- and PVC-free, Halogen-free in accordance with DIN EN 50267-2-1, IEC 60754-1, VDE 0482-267-2-1, Approvals: Ecolab, FDA, RoHS and REACH compliant, protection class IP67, IP69K, cable length 2 m, EAN: 4047101388985.

Key specifications

Cable length
2 m
Plug type
M12
Item number
36622591

General information

Manufacturer
Turck
Category
Power cables
Manufacturer no.
6935412
Release date
22.6.2023

Power cable properties

Plug type
M12
Plug type
Flat

Origin

Country of origin
China

Voluntary climate contribution

CO₂-Emission
Climate contribution

Product dimensions

Cable length
2 m
