Turck Actuator-

Turck Actuator and sensor cable WKC4.4T-P #6628875 Manufacturer :Turck Designation :Actuator and sensor cable Welding spark resist. Type :WKC4.4T-P #6628875 Number of poles :4 Type of electrical connection, field side :M12 Type of plug contact, field side :Male Arrangement of cable feed, field side :Straight Type of electrical connection, housing side :M12 Type of plug contact, housing side :Female Cable feed arrangement, housing side :Angled Cable length :0.6 m Cable sheath material :Polyurethane (PUR) Cable sheath colour :Yellow With LED indicator :Yes Shielded :No Cable type :Multi-core Contact base material :CuZn Contact coating material :Gold Perm. Permissible external cable temperature after installation without vibration :-50..105 °C Permissible external cable temperature during installation/handling :-30..90 °C Rated current In :4 A Rated voltage :30 V Turck actuator and sensor cable WKC4.4T-P #6628875: more details Welding spark resistant actuator and sensor cable, connecting cable, M12 coupling, angled, 4-pin, with 3 LEDs (pnp, red, yellow, green), cable length: 0.6 metres, sheath material: PUR coated with aramid fibres, sheath colour: yellow, resistant to welding sparks, flame retardant, resistant to chemicals, UV and oil, halogen, silicone, PVC and LABS-free, RoHS-compliant, protection class IP67, protective sheath material: Aramid fibres, Tensile strength: 2923 MPa, Breaking strength: 333 N, Elongation at break: 3.6%, Temperature peaks: up to 200°C, M12 plug, straight, 4-pin , EAN: 4047101329216.
