MeanWell DC/DC converter

1Ratings
BrandMore from MeanWell
Delivered between Tue, 7.4. and Fri, 10.4.
More than 10 pieces in stock at third-party supplier
Supplied by
free shipping

input voltage2

Output voltage2

Power output4

Product details

The MeanWell DC/DC converter, model SD-500H-24, is a powerful voltage converter designed for a variety of applications. With a rated power of 504 watts and a maximum output voltage of 30 V, this device offers a high efficiency of 89%. The converter is capable of handling input voltages between 72 V and 144 V and delivers a stable output voltage of 24 V at a maximum output current of 21 A. The robust aluminum housing ensures reliable performance under various conditions, while the integrated protection mechanisms such as short circuit protection and over-temperature protection ensure the safety of the device. The converter is suitable for use in a temperature range of -20 °C to 60 °C and offers a long lifespan with a mean time between failures (MTBF) of 196,300 hours.

  • Adjustable output voltage between 23 V and 30 V
  • Protection mechanisms: Reverse Polarity Protection, Short Circuit Protection, Overvoltage Protection, Overtemperature Protection, Overload Protection
  • Input voltage range of 72 V to 144 V
  • High efficiency of 89%
  • Isolation voltage of 2 kV.

Key specifications

Voltage transformer type
Vehicle voltage transformer
input voltage
144 V
Output voltage
24 V
Power output
504 W
Length
21.50 cm
Width
11.50 cm
Height
5 cm

General information

Item number
8496547
Manufacturer
MeanWell
Category
Power inverters
Manufacturer no.
SD-500H-24
Release date
21.4.2018
External links
Manufacturer's site (de)

Colour

Colour
Silver
Exact colour description
Metallic

Voltage Transformer Properties

Voltage transformer type
Vehicle voltage transformer
input voltage
144 V
Output voltage
24 V
Power output
504 W
Electric current output
21 A

Origin

Country of origin
China

Voluntary climate contribution

CO₂ emissions
29.26 kg
Climate contribution
CHF 0.70

Product dimensions

Length
21.50 cm
Width
11.50 cm
Height
5 cm
Weight
1116.67 g
