Lenovo DCG ThinkSystem SR550
Intel Xeon Silver 4208, 16 GB, Rack ServerProduct details
The ThinkSystem SR550 impresses with a balanced mix of performance and capacity in a 2U form factor. Essential performance components are provided in a combination that enhances the cost efficiency of the system. This allows the SR550 to meet not only the workload requirements but also the budget needs of businesses.
New Intel Xeon Scalable CPUs (2nd generation) deliver 36% more performance than the previous generation, support for faster 2933MHz TruDDR4 memory, and Intel's Vector Neural Network Instruction (VNNI). This feature boosts processor performance for deep learning and AI workloads. An increase of up to 6% in performance per core, along with hardware-based security features, rounds out the optimized characteristics found in Intel's new processors.
The Lenovo XClarity Controller is a management engine embedded in all ThinkSystem servers, designed to standardize, simplify, and automate server management tasks. The Lenovo XClarity Administrator is a virtualized application that centrally manages ThinkSystem servers, storage, and network components, potentially reducing deployment time by up to 95% compared to manual operations. By operating XClarity Integrator, you can optimize IT management, accelerate deployment, and control costs through seamless integration of XClarity into an existing IT environment.
Number of rack units | 2 U |
Processor family | Xeon |
Processor type | Intel Xeon Silver 4208 |
Max. number of hard disks | 16 |
Number of processors | 1 x |
RAM | 16 GB |
Operating system | No operating system |
Item number | 13174464 |
Manufacturer | Lenovo |
Category | Servers |
Manufacturer no. | 7X04A07JEA |
Release date | 6.5.2020 |
External links |
Design | Rack Server |
Number of rack units | 2 U |
Processor family | Xeon |
Processor type | Intel Xeon Silver 4208 |
Number of processors | 1 x |
Number of processor sockets | 1 x |
Clock frequency | 2.10 GHz |
Number of threads | 16 |
Number of processor cores | 8 -Core |
Max. turbo clock rate | 3.20 GHz |
Max. TDP | 85 W |
L3 Cache | 11 MB |
Socket | Socket P |
Chipset | Intel C622 |
Memory type | DDR4-RAM |
Max. memory slots | 12 |
Memory configuration | 1 x 16GB |
RAM | 16 GB |
Max. RAM | 384 GB |
RAM speed | 2666 MHz |
RAM error correction | ECC |
RAID configuration | 0, 1, 10, 5, 50, 6, 60, JBOD |
Possible raid configuration | 0, 1, 10, 5, 50, 6, 60, JBOD |
Mass storage controller type | SAS |
Data storage controller | Intel C622 |
Max. number of hard disks | 16 |
Form factor | 3.5" |
Interface | SAS, SATA III |
Hard disk additional functions | Hot swapping |
Expansion slot | PCI Express x8 (1x) |
PCI express version (max.) | 3 |
USB ports | USB-A |
Exact USB ports | USB-A 3.0 (3x) |
Data ports | PS/2 (1x) |
Connectivity | Ethernet |
Network connections | RJ45 Gigabit Ethernet (2x) |
Max. port speed | 1000 Mbit/s |
Graphics card model | Matrox G200e |
Video memory type | GDDR4 |
Graphics chip (GPU) | Matrox |
Dedicated graphics memory | 200 GB |
Hardware interface | RJ45, USB 2.0, USB 3.0 |
Optical drive type | No drive |
Operating system | No operating system |
Processor design | 64-bit |
Number of power supply units | 1 x |
Power | 750 W |
input voltage | 230 V |
Max. number of power supply units | 1 |
Manufacturer commitment | SBTi |
CO₂-Emission | |
Climate contribution |
Length | 763.70 mm |
Width | 482 mm |
Height | 86.50 mm |
Weight | 19 kg |
