Lapp 64400120

Lapp Accessories SILVYN AS-P 11/13x17 10m 64400120 Manufacturer :Lapp Accessories Designation :SILVYN AS-P 11/13x17 10m GY Type :64400120 Nominal diameter :17 mm Nominal size in inches :3/8 inch Outer diameter :17 mm Inner diameter :13 mm Material :Steel Surface protection :galvanised Sheathing material 1. Sheathing material :Polyvinyl chloride (PVC) Sheathing material 2nd layer (outer) :without sheathing Seal :without seal Pressure resistance :750 N Operating temperature :-25...80 °C Protection class (IP) :IP68 Tensile strength :500 N Bending radius, static :45 mm Weight :0.17 kg/m Colour :grey Suspension load :150 N Electrical properties :with conductive properties Flame-spreading :yes Bending behaviour :flexible FI approval :no With UL approval :no Lapp accessories SILVYN AS-P 11/13x17 10m 64400120: Further details Mechanical engineering, Plant engineering, Automation technology, Wherever liquids are present, Mechanically demanding environment, Protects against liquids, Tensile strength, IncreasedFlexible, Increased mechanical load-bearing capacity, Spiral-wound metal conduit with hook-in profile, PVC sheath, VDE, DIN 49012, Complies with type I according to DIN EN IEC 61386-23, In EX areas according to EN 1127-1, , EAN: 4044773280586.
