HPE E ProLiant DL380 Gen11 NC 32 Core, RDIMM 2R 4800 MT/s, 8xSFF, 1xPS
Intel Xeon Gold 6430, 64 GB, Rack ServerProcessor type2
Product details
Are you looking for a scalable dual-socket server solution for your data analytics or hybrid cloud workloads? The HPE ProLiant DL380 Gen11 Server is a scalable 2U 2P solution that offers exceptional computing power, storage density with scalability, and high-speed data transfer rates to run your most demanding applications. Based on the scalable Intel Xeon processors of the 4th and 5th generations with up to 64 cores, 8 TB of memory, and 20 EDSFF drives, along with increased memory bandwidth and high-speed PCIe Gen5 I/O, the HPE ProLiant DL380 Gen11 Server is an ideal solution for software-defined storage, video transcoding, and virtualized applications. The HPE ProLiant DL380 Gen11 Servers are designed to optimize IT. With a cloud operating experience, integrated security, and optimized workload performance, your business will be propelled forward.
Processor family | Xeon Gold |
Operating system | No operating system |
Processor type | Intel Xeon Gold 6430 |
Max. number of hard disks | 8 |
Number of processors | 1x |
RAM | 64 GB |
Number of rack units | 2 U |
Item number | 25429151 |
Design | Rack Server |
Number of rack units | 2 U |
Processor family | Xeon Gold |
Processor type | Intel Xeon Gold 6430 |
Number of processors | 1x |
Number of processor sockets | 2x |
Clock frequency | 2.10 GHz |
Number of processor cores | 32 -Core |
Max. turbo clock rate | 3.40 GHz |
Max. TDP | 270 W |
L3 Cache | 60 MB |
Socket | LGA 4677 |
Chipset | Intel C741 |
Memory type | DDR5 RAM |
Max. memory slots | 32 |
Memory configuration | 2 x 32GB |
RAM | 64 GB |
Max. RAM | 8192 GB |
RAM speed | 4800 MHz |
RAM error correction | ECC |
RAM buffer | Registered |
RAID configuration | 1 |
Possible raid configuration | 0, 1, 10, 5, 50, 6, 60 |
Mass storage controller type | SAS, SATA III |
Max. number of hard disks | 8 |
Form factor | 2.5" |
Interface | SAS, SATA |
Interface version | SATA III |
Hard disk additional functions | Hot swapping |
Expansion slot | PCI Express x16 (1x), PCI Express x8 (2x) |
PCI express version (max.) | 5 |
Internal connection options | PCI Express x16 (1x) |
USB ports | USB-A |
Exact USB ports | USB-A 3.2 Gen 1 (3x) |
Data ports | RS-232 (1x) |
Connectivity | Ethernet |
Network connections | RJ45 Gigabit Ethernet (2x), SFP28 (2x) |
Ethernet controller | Broadcom 57414 |
Ethernet controller brand | Broadcom |
Video memory type | Shared Memory |
Dedicated graphics memory | 0.02 GB |
Hardware interface | Ethernet, RJ45, USB 3.0 |
Video connections | D-Sub (1x) |
Optical drive type | No drive |
Operating system | No operating system |
Processor design | 64-bit |
Number of power supply units | 1x |
Power | 1000 W |
input voltage | 100 - 240 V |
Max. number of power supply units | 2 |
Manufacturer commitment | SBTi |
CO₂-Emission | |
Climate contribution |
Length | 727 mm |
Width | 448 mm |
Height | 87.50 mm |
Weight | 16 kg |
