Gelid TP-GP04-A
0.50 mm, 15 W/m KFree shipping starting at 50.–
The GP-Ultimate is designed to provide perfect thermal contact to heatsinks when installed on PCBs with height differences and uneven surfaces, such as power MOSFETs, chipsets, analog ICs, micro-controller units, and other high-temperature SMD components. Thanks to its enhanced multilayer matrix, superior material composition, and ultimate thermal conductivity, the GP-Ultimate fills spaces properly and offers the best performance in its class.
The GP-Ultimate is non-electrically conductive, non-corrosive, non-curing, non-toxic, and supports an extended operating temperature range of -60°C to 220°C. It features easy application and has thermal pad dimensions of 90x50mm to best fit large PCB surfaces of GPU cards, motherboards, add-on cards, and any other densely packed electronic device.
Length | 90 mm |
Width | 50 mm |
Thickness | 0.50 mm |
Density | 3.20 g/cm³ |
Shore hardness | Shore 00-60 |
Electrical conductivity | Non-conductive (0 S/m) |
Max. temperature | 220 °C |
Item number | 35748399 |
Manufacturer | Gelid |
Category | Thermal pads |
Manufacturer no. | TP-GP04-A |
Release date | 21.5.2023 |
Sales rank in Category Thermal pads | 31 of 213 |
Colour | Grey |
Thermal paste type | Heat conducting pad |
Thermal conductivity | 15 W/m K |
Max. temperature | 220 °C |
Density | 3.20 g/cm³ |
Shore hardness | Shore 00-60 |
Electrical conductivity | Non-conductive (0 S/m) |
Items per sales unit | 1 x |
CO₂-Emission | |
Climate contribution |
Length | 90 mm |
Width | 50 mm |
Thickness | 0.50 mm |
Weight | 16 g |
