Flexa Secure screw connection

Cable conduit, 3.30 cm
CHF930.–/1m
Ratings
BrandMore from Flexa
Delivered between Mon, 30.6. and Wed, 2.7.
More than 10 items in stock at third-party supplier
Supplied by
Free shipping starting at 50.–

Product details

Flexa Safety Screw Connection US-M 5010.328.016

Manufacturer: Flexa
Description: Safety Screw Connection AD17/M16
Type: US-M 5010.328.016
Nominal Diameter: 17 mm
Nominal Size in Inches: 3/8 inch
Protection Class (IP) dependent on hose: 0..65
Design: Straight
Rotatable Thread: No
Design Type: External Thread
Connection Type of the Screw Connection to the Housing: Thread
Thread Type: Metric
Thread Connection Size: M16 x 1.5
Threads per Inch: 1.5
One-Piece: No
Housing Material: Brass
Surface Protection: Nickel Plated
Smallest Inner Diameter of the Hose: 13 mm
Largest Outer Diameter of the Hose: 17 mm
Thread Length: 10 mm
Total Length: 33 mm
Total Height: 27 mm
Approval in Combination with Protective Hose according to DIN EN 61386-23: Yes
Approval in Combination with Protective Hose CSA: No
Approval in Combination with Protective Hose UL: No
Approval in Combination with Protective Hose FI: No
Operating Temperature: -40..125 °C
Number of Entries: 1
With Ground Connection: No

Flexa Safety Screw Connection US-M 5010.328.016: Additional Details
Metal Safety Screw Connection Straight US-M, IP 65 suitable for Metal Protective Hoses SPR-PA / SPR-PU-AS / SPR-PU-F / SPR-PVC-AS / FLEXAgraff-PU-AS / FLEXAgraff-PU-F
Metric External Thread, including Inner Sleeve, Sealing Ring, and O-Ring, Housing with Hex Key Surface
Material: Nickel Plated Brass
Temperature Range: -40 °C to +125 °C
Features: High dust and liquid protection, force-fit connection of hose and screw connection, reliable grounding, covering of hose ends, vibration and pull-resistant.
EAN: 4025113145475.

Key specifications

Height
27 mm
Exact colour description
Silver
Material
Brass
Item number
21350053

General information

Manufacturer
Flexa
Category
Cable trunking
Manufacturer no.
15010328016
Release date
29.6.2022

Colour

Colour
Silver
Exact colour description
Silver

Material

Material group
Metal
Material
Brass

Cable duct properties

Cable duct type
Cable conduit

Safety

Protection type (IP code)
IP65

Origin

Country of origin
Germany

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 pcs.

Product dimensions

Height
27 mm
Diameter
17 mm
Length
3.30 cm
