Finder Installation contactor series 22, 25 A 22.32.0.024.4340 2 NO contacts (30/110/220 V) 25/5/1 A

1Ratings
BrandMore from Finder
Delivered between Wed, 8.4. and Thu, 9.4.
More than 10 pieces in stock at third-party supplier
Supplied by
Free shipping starting at 50.–

input voltage2

Output voltage3

Product details

Description Installation contactor Series 22, 25 A Installation contactors to DIN EN 61095: 2009. For switching high inrush currents up to 120 A for 5 ms at the make contacts (lamp loads). Contacts with double break. Via internal circuitry for AC/DC control (hum-free). Reinforced insulation between coil and contacts. Auxiliary switch with 1 NO + 1 NC or 2 NO contacts can be mounted on the side. For DIN EN 60715 TH35 rail. Equipment: Mechanical indicator Electrical indicator (LED) On-auto-off switch. Technical data: Drop-out time: 20 ms Response time: 30 ms Switch-on current: (5 ms) Max. 120 A Contact type: 2 NO contacts Contact material: AgSnO 2 Service life (electrical): 30 x 10 3 switching cycles Lifetime (mechanical): 2 x 10 6 operations Rated voltage: 24 V DC/AC Rated current: (AC-7b, AC-7c) 10 A Product dimension, width: 17.5 mm Product dimension, height: 60.8 mm Switching capacity: (AC1/AC-7a) Max. 6250 VA/(AC15, 230 V/AC) 1800 VA Switching voltage: 250 V/AC/Max. 440 V/AC Switching current:.

Key specifications

Relay type
Installation contactor
input voltage
24 V
Output voltage
250 V
Electric current output
25 A
Number of poles
2x

General information

Item number
31067223
Manufacturer
Finder
Category
Relays
Manufacturer no.
22.32.0.024.4340
Release date
6.12.2021
Sales rank in Category Relays
69 of 16706

Relay properties

Relay type
Installation contactor
input voltage
24 V
Output voltage
250 V
Electric current output
25 A
Switching function
Normally open
Number of openers
0x
Number of closers
2x
Number of poles
2x
Max. Switching capacity
6.25 kW

Smart home features

Smart home
Not compatible

Origin

Country of origin
China

Voluntary climate contribution

CO₂ emissions
11.48 kg
Climate contribution
CHF 0.27

Scope of delivery

Scope of delivery
Cam bridge, Installation contactors, Mounting foot for chassis mounting

Product dimensions

Length
60.80 mm
Width
17.50 mm
Height
84 mm

Package dimensions

Length
12.10 cm
Width
6.90 cm
Height
3.10 cm
Weight
100 g
