Dehn Downpipe clamp 60-100mm St/tZn w. 423010

DEHN rainwater pipe clamp RRSV60100B105STTZN

Manufacturer: DEHN
Description: Rainwater pipe clamp 60-100mm
Type: RRSV60100B105STTZN
Clamping/tensioning range: 60...100 mm
Material: Steel
Surface protection: Hot-dip galvanised
Two-metal connector: No
Connection hole: 10.5 mm

Further details: Pipe clamp in accordance with DIN EN 62561-1, for connecting rainwater downpipes to lightning equipotential bonding in accordance with DIN EN 62305-3. Connection options D11 mm for round conductors, e.g., with KS connector or with clamping block. Type RV adjustable for different tube diameters, with additional anti-rotation protection of the fixing screw M8 and markings, predetermined bending points as well as stamped cutting aids. EAN: 4013364054325.
