APC USV SRT1000XLI 1000VA/1000W

1000 VA, 1000 W, Online double converter UPS
Ratings
BrandMore from APC
Delivered between Wed, 29.7. and Thu, 30.7.
Only 1 piece in stock at supplier
free shipping

Product details

Schneider Elec. (APC) APC Smart-UPS SRT On-Line SRT1000XLI

Manufacturer: Schneider Elec. (APC)
Designation: APC Smart-UPS SRT On-Line 1000VA 230V
Type: SRT1000XLI
Input Voltage: 230 V
Primary Frequency: 40–70 Hz
Number of Primary Phases: 1
Output Voltage: 230 V
Secondary Frequency: 50–60 Hz
Output Active Power: 1000 W
Output Apparent Power: 1000 VA
Power Consumption: 1000 W
USB Interface: yes
With RS-232 Communication Interface: no
Number of Secondary Phases: 1
SNMP: no
Voltage Type: AC
Height: 432 mm
Width: 85 mm
Depth: 505 mm
Weight: 20.5 kg
Full Load Backup Time: 8.27 min
Network Management Capable: no
UPS Technology: Online
Form Factor: Tower
Modular: no
Max. Output Voltage Distortion (linear load): 0.02 %
Output Power Factor: 1
Overall Efficiency: 88 %
Efficiency in Eco Mode: 94 %
Potential-Free Relay Contact: no
Automatic Shutdown Function: no
Input Connection: C14
Number of Output Connections (C13): 6

High-performance UPS system with double-conversion online technology and scalable autonomy time. Not suitable for consumers in the EU. EAN: 0731304340270.

Key specifications

UPS protection functions
Overvoltage protection
Scope of application
Server room
Plug type
C13
Operating time at full load
8 min
Operating time at half load
21 min
Battery type
Lead–acid battery

General information

Item number
11463828
Manufacturer
APC
Category
UPS
Manufacturer No.
SRT1000XLI
Release date
11.7.2019

UPS properties

UPS type
Online double converter UPS
Power output
1000 W
Output power capacity
1000 VA
Rack height units
3 U
shaft type
Sine wave

UPS functions

UPS protection functions
Overvoltage protection

Application range

Scope of application
Server room

Connections

USB ports
USB-A
Network connections
RJ45 (1x)
Data ports
RS-232 (1x)

Operating conditions

Maximum operating temperature
40 °C
Operating temperature
0 - 40 °C
Operating humidity
0% - 95%
Max. noise level
50 dB
Protection type (IP code)
IP20

Mains supply properties

Plug type
C13
Min. input voltage
100 V
Output voltage
50 - 240 V
Min. output voltage
50 V
Max. output voltage
240 V
Max. input current
10 A
Input frequency
40 / 70 Hz
Output frequency
50 - 60 Hz
overvoltage protection
432 J

Battery properties

Operating time at full load
8 min
Operating time at half load
21 min
Battery category
Device batteries
Battery
Rechargeable battery
Battery type
Lead–acid battery
Battery weight per cell
29600 g
Capacity
9 Ah
Charging time
3 h

Origin

Country of origin
China

Voluntary climate contribution

CO₂ emissions
115.78 kg
Climate contribution
CHF 2.76

Scope of delivery

Scope of delivery
CD with software, Communication cable, Documentation C, USB cable
Items per sales unit
1x

Product dimensions

Height
432 mm
Weight
20.50 kg
Width
85 mm
Length
749 mm

Package dimensions

Length
50 cm
Width
50 cm
Height
20 cm
Weight
10 kg
