Product details
Weidmüller relay coupler TRS 24-230VUC1CO 16A Manufacturer :Weidmüller Designation :Relay coupler 24-230V UC+/-10% 16A Type :TRS 24-230VUC1CO 16A Electrical connection type :Screw connection With detachable terminals :no Rated current :16 A Rated control supply voltage Us at AC 50 Hz :21,6..253 V Rated control supply voltage Us at AC 60 Hz :21.6..253 V Rated control supply voltage Us at DC :21.6...253 V Voltage type for actuation :AC Actuator, polarity :non-polarised Switching behaviour of the actuator :monostable Number of contacts as changeover contacts :1 With positively driven contacts :no Type of switching contact :Single contact Complete device with base :yes With LED display :yes Protection class (IP) :IP20 Width :12.8 mm Height :89.6 mm Depth :87.8 mm Weidmüller relay coupler TRS 24-230VUC1CO 16A: further details Assembly consisting of plug-in relay and plug-in base. Control circuit and load circuit are galvanically isolated. , EAN: 4050118288063.
Scope of delivery | Alternative (alias)=TRS 24-230VUC 1CO 16A, Coil voltage - AC=230 V, Coil voltage - DC=230 V, Connection type=screw terminal, Contact configuration=1 changeover contact, Contact material=AgNi, Height=89.6 mm, Length=87.8 mm, Mounting type=DIN rail mounting, Protection class = IP20, Relay module, Series=TERMSERIES, Switching capacity=4 kVA, Switching current=16 A, Switching voltage - AC=250 V, Switching voltage - DC=250 V, Type of coil = AC / DC, Type=1479770000, Width=12.8 mm |
Output current type | AC |
Electric current output | 16 A |
Relay type | Switching relay |
Item number | 32349537 |
Manufacturer | Weidmüller |
Category | Relays |
Manufacturer no. | 1479770000 |
Release date | 28.6.2023 |
Relay type | Switching relay |
Electric current output | 16 A |
Output current type | AC |
Manufacturer Type | TRS 24-230VUC1CO 16A |
Smart Home | Not compatible |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Scope of delivery | Alternative (alias)=TRS 24-230VUC 1CO 16A, Coil voltage - AC=230 V, Coil voltage - DC=230 V, Connection type=screw terminal, Contact configuration=1 changeover contact, Contact material=AgNi, Height=89.6 mm, Length=87.8 mm, Mounting type=DIN rail mounting, Protection class = IP20, Relay module, Series=TERMSERIES, Switching capacity=4 kVA, Switching current=16 A, Switching voltage - AC=250 V, Switching voltage - DC=250 V, Type of coil = AC / DC, Type=1479770000, Width=12.8 mm |
Length | 87.80 mm |
Width | 12.80 mm |
Height | 89.60 mm |
