It was designed for monitoring and recording measured voltage data. The recording of this voltage data logger, whose capacity is designed for storing a large number of measurement data, is based on adjustable criteria.Individually configurable via browserThe configuration of the logger can be carried out individually and according to requirements via the web browser. As soon as the data recording is completed and the logger is connected to a USB interface, a PDF file and an additional spreadsheet file are automatically generated. This record contains general information about the device, the data logger settings, the alarm status and a graph showing the measured values during the recorded time.
measurements | Suspense |
Item number | 15974424 |
Manufacturer | Voltcraft |
Category | Metrology |
Manufacturer no. | VC-11015505 |
Release date | 4.6.2021 |
Colour | Red |
Type of measuring technique | Measuring device case |
measurements | Suspense |
Min. input voltage | 0.01 V |
Max. input voltage | 30 V |
Temperature range | 0° - 55° C |
Calibrated according to | Factory standard (without certificate) |
Manufacturer Type | VC-11015505 |
Digit height | 0.25 mm |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Scope of delivery | Data logger CD operating instructions 1 x CR2450 battery |
Length | 93 mm |
Width | 37 mm |
Height | 19 mm |
Weight | 59 g |
