Victron Energy Solar panel 20W-12V, Polycrystalline

Features Low temperature-voltage coefficient ensures high efficiency even at high temperatures. Exceptional performance even in low light conditions and high light sensitivity across the entire solar spectrum. 25 year limited warranty on power output and performance. 5-year limited warranty on materials and workmanship. Sealed, waterproof, multifunctional junction box provides a high level of security. High-performance bypass diodes minimise current drop caused by shading. The advanced EVA (ethylene vinyl acetate) encapsulation system with three-layer backsheet complies with the most stringent safety regulations for high voltage operation. A sturdy, anodised aluminium frame allows the modules to be easily attached to the roof using a range of standard mounting systems. The highest quality, high transmittance Sekurit glass provides enhanced strength and impact resistance. High performance models with pre-wired quick connection system with MC (PV-ST01) connectors. Technical data Rated power 20Wp Voltage at max. power Vmpp 18.4V Current at max. power Impp 1.09A Open circuit voltage Voc 21.96V Short circuit current Isc 1.18A Number of cells in series 36 Temperature range -40°C to 85°C Max. surface load 200kg/m^2 Surface load 200kg/m^2 Permissible load hail 23m/s 7.53g Connection no cable Output tolerance +/-3 % Frame aluminium Weight 1.9 kg Data sheet polycrystalline panel 20Wp General information about solar technology can be found at: Things to know about solar technology General information about batteries can be found at: Things to know about batteries General information about charging batteries can be found at: Interesting facts about charging batteries
