Output voltage: 15V DC
Output current: 5A
Rated power: 75W
Number of outputs: 1
Input voltage: 90 to 264V AC
Mounting type: Cabinet mounting
Enclosure type: Closed
Length: 129mm
Width: 99mm
Depth: 38mm
Load regulation: 2%
Mains regulation: 0.5%
Efficiency: 86%
Maximum temperature: +70°C
Minimum temperature: -20°C
This product complies with UL 60950-1, IEC 60950-1, and EN 60950-1 standards. It features a universal input range from 15W to 150W with a single output, part of the TXM series by Traco Power. The TXM series is designed for a range of cost-critical applications and comes in metal enclosures. These power supplies have a low-profile housing and screw terminal block connections for easy installation. They also comply with European EMC standards and the Low Voltage Directive (LVD). The design is cost-optimized with low no-load power consumption, and the screw terminal block models up to 150W do not include an internal fan. The output voltage is adjustable.
| input voltage | 264 V |
| Output voltage | 16.50 V |
| Power output | 15 W |
| Voltage transformer type | Vehicle voltage transformer |
| Length | 9.90 cm |
| Width | 12.90 cm |
| Height | 3.80 cm |
| Item number | 10323501 |
| Manufacturer | TracoPower |
| Category | Power inverters |
| Manufacturer no. | TXM 075-115 |
| Release date | 15.1.2019 |
| Voltage transformer type | Vehicle voltage transformer |
| input voltage | 264 V |
| Output voltage | 16.50 V |
| Power output | 15 W |
| Electric current output | 5 A |
| CO₂-Emission | |
| Climate contribution |
| Length | 9.90 cm |
| Width | 12.90 cm |
| Height | 3.80 cm |
| Weight | 380 g |
