TE Connectivity Contactor 900A NO, 9-36Vdc coil w/aux

Ratings
BrandMore from TE Connectivity
Delivered between Wed, 5.8. and Fri, 7.8.
More than 10 pieces in stock at third-party supplier
Supplied by
free shipping

Product details

Coil voltage: 36V DC
Contact arrangement: 1 pole normally open contact
Switching current: 500 A
Connection type: Screw
Series: EV200
Switching voltage DC max: 900V
Application type: High voltage
Length: 80.48mm
Depth: 65.6mm
Height: 72.3mm
Dimensions: 80.48 x 65.6 x 72.3mm
Operating temperature max: +85°C

High voltage relay (contactor) - EV200 series. Typical applications include battery and reserve switching, DC power control, circuit protection, and safety. It is small and lightweight, hermetically sealed, with an operating voltage of 12-900 VDC, a 500 A current carrying capacity, and 2000 A interruption at 320 VDC. It features an integrated coil distributor for 1.7 W holding power at 12 VDC and an ambient temperature range of -40 to +85°C. Bottom mounting with 10 mm connector and M8 terminals.

Key specifications

Electric current output
500000 mA
Number of poles
1x

General information

Item number
9910994
Manufacturer
TE Connectivity
Category
Relays
Manufacturer No.
EV200HAANA 1-1618002-8
Release date
16.10.2018

Relay properties

Electric current output
500000 mA
Switching function
Normally open
Number of closers
1x
Number of poles
1x

Voluntary climate contribution

CO₂ emissions
29.26 kg
Climate contribution
CHF 0.70

Scope of delivery

Scope of delivery
1 piece

Product dimensions

Length
80.40 mm
Width
65.40 mm
Height
72.40 mm
