The Supermicro A+ Server 1114S-WTRT is a powerful rack server designed for demanding applications in data centers and enterprise environments. With an SP3 socket, it offers the flexibility to integrate various AMD EPYC processors to tailor computing power to specific requirements. The server supports up to 2048 GB of DDR4 RAM, providing high memory capacity for data-intensive applications. The hot-swappable 2.5-inch drive bays allow for easy maintenance and expansion of storage capacity, while the 10GBase-T LAN ports ensure fast network connectivity. The redundant 500W power supplies with platinum efficiency provide reliable power and energy efficiency, which is critical for operation in business-critical environments. The server is designed to support a wide range of applications and offers a robust foundation for modern IT infrastructures.
Number of CPU sockets | 1 x |
Socket | SP3 |
Processor family | AMD 7000 Series |
Max. memory slots | 8 |
Item number | 13389178 |
Manufacturer | Supermicro |
Category | Server barebones |
Manufacturer no. | AS-1114S-WTRT |
Release date | 18.3.2022 |
Sales rank in Category Server barebones | 17 of 429 |
May include power adapter | Yes |
Design | Rack Server |
Number of rack units | 1 U |
Manufacturer | Supermicro |
Number of CPU sockets | 1 x |
Socket | SP3 |
Processor family | AMD 7000 Series |
Memory type | DDR4-RAM |
Memory form factor | DIMM |
Number of pins | 288 x |
Max. memory slots | 8 |
Max. RAM | 2000 GB |
RAM speed | 3200 MHz |
RAM error correction | ECC |
RAM buffer | Registered |
Max. number of hard disks | 12 |
Storage capacity | 0 GB |
Form factor | 2.5", M.2 |
Interface | Mini PCIe, SATA |
Interface version | SATA III |
USB ports | USB-A |
Exact USB ports | USB-A 3.0 (7x) |
Connectivity | Ethernet |
Internal connection options | S-ATA III (2x) |
Expansion slot | PCI Express x16 (3x) |
PCI express version (max.) | 4 |
Network connections | RJ45 (2x) |
Ethernet controller | Broadcom 57416 |
Ethernet controller brand | Broadcom |
Max. port speed | 10000 Mbit/s |
Video connections | D-Sub (1x) |
Number of power supply units | 2 x |
Max. number of power supply units | 2 |
Power | 500 W |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Length | 630 mm |
Width | 437 mm |
Height | 43 mm |
Weight | 20.90 kg |
Length | 79 cm |
Width | 60 cm |
Height | 19 cm |
Weight | 1.60 kg |
