StarTech 2 Port VGA Auto Switching Video Switch

Device Type: Switch
Video Connection Type: VGA
Number of Video Outputs: 1
Maximum Resolution: 2048 x 1536
Dimensions: 195 x 130 x 5.6 mm
Weight: 930 g
Depth: 130 mm
Height: 5.6 mm
Width: 195 mm

VGA Auto Switch with 2 Ports. The ST122VGAU VGA automatic switch allows you to share a display between two computers and prioritize your VGA signals. The VGA switch features a primary and secondary VGA input port and automatically outputs a signal through the main input. If the signal feed connected to the primary input port is interrupted, the switch automatically switches to the video signal from the secondary VGA input port. The VGA automatic switch is designed for maximum control and versatility, providing manual control of the connected signals with easy-to-use front panel buttons that allow you to switch between video sources. It automatically selects the priority of incoming video signals for display and supports resolutions up to 1920 x 1440. Operation is simple via the front panel selection buttons. Installation is straightforward and can be completed in just a few minutes. The video bandwidth is 250 MHz, and the robust steel housing ensures durability. The switch supports DDC1, DDC2, DDC2B, DDC2B+, and DDC2AB on port 1.

Applications: Ideal for use with a laptop computer and a conference room projector in meetings and presentations, backup security control systems, and home A/V switching applications. Perfect for digital signage applications in retail that require connecting more than one media player or PC. Excellent for connecting/switching multiple sources in test stand facilities, data centers, help desks, and video transmission facilities.
