All firewall appliances in the XGS series are based on a dual-processor architecture that combines a high-performance multi-core CPU with a dedicated Xstream Flow processor for targeted hardware-level acceleration. This provides you with the flexibility and adaptability of an x86-based firewall, along with a significant performance boost compared to older firewall designs. The 1U models are particularly suitable for medium-sized and distributed enterprises that require a powerful, flexible solution for operating and protecting their networks. These rack-mounted firewalls offer top-tier performance, a variety of integrated high-speed interfaces, and a selection of additional add-on connection modules. Whether you want to ensure maximum uptime for your SD-WAN connections, secure the connection for your remote users, or protect the network in a growing business, you can customize the firewalls to fit your dynamic environment. Firewall throughput: 30 Gbit/s. Firewall throughput (IMIX): 15.9 Gbit/s. IPS throughput: 5.8 Gbit/s. Firewall latency (64-byte UDP): 6 µs. Threat protection throughput: 1.25 Gbit/s. Xstream SSL/TLS inspection: 1.1 Gbit/s.
UTM  | Antivirus, Content filter, IDP, Spam filters  |
Firewall throughput rate  | 30000 Mbit/s |
VPN throughput  | 17000 Mbit/s |
Max. port speed  | 1000 Mbit/s |
Item number  | 18174084 |
Manufacturer  | Sophos |
Category  | Firewalls |
Manufacturer no.  | XG2ATCHEUK |
Release date  | 19.8.2023 |
Sales rank in Category Firewalls  | 14 of 937 |
Model  | 19" rack  |
Firewall throughput rate  | 30000 Mbit/s |
VPN throughput  | 17000 Mbit/s |
AV data throughput  | 1250 Mbit/s |
IDP data throughput  | 17000 Mbit/s |
Max. IPSec VPN Tunnels  | 5000 |
Max. sessions  | 6500000 |
UTM  | Antivirus, Content filter, IDP, Spam filters  |
Number of ports  | 8 ports |
Network connections  | RJ45 (1x), RJ45 (8x), SFP (2x)  |
Max. port speed  | 1000 Mbit/s |
USB ports  | USB-A  |
Connectivity  | Ethernet  |
Power consumption  | 462 W |
Maximum operating temperature  | 40 °C |
CO₂-Emission  | |
Climate contribution  |
Scope of delivery  | Rack mounting lugs  |
Width  | 438 mm |
Length  | 405 mm |
Height  | 44 mm |
Weight  | 4700 g |
