somfy Radio receiver

Somfy radio receiver 1811244

Manufacturer: Somfy
Designation: Radio receiver UP, RTS for shutters
Type: 1811244

Suitable for dimmers: No
Suitable for pulse pushers: Yes
Suitable for shutter switches: Yes
Suitable for blind switches: Yes
Suitable for shutter/blind switches: Yes
Suitable for switches: Yes
In housing: Yes
In tube base housing: No
As module/board: Yes
Power supply: Other
Push-button operation: Yes
Switching operation: Yes
With radio hand-held transmitter: No
With radio coding device: No
With radio push-button: No
Mounting type: Flush-mounted
Material: Other
Material grade: Other
Halogen-free: No
Surface protection: Other
Color: White
Transparent: No
Suitable for protection class (IP): IP20
Protection class (NEMA): Other
Radio frequency: 433.42 MHz
Rolling code system: Yes
Compatible with Apple HomeKit: No
Compatible with Google Assistant: No
Compatible with Amazon Alexa: No
IFTTT support available: No

Submersible receiver RTS for shutters. Existing switches/buttons can continue to be used. Suitable for flush-mounted boxes from 50mm depth. Up to 12 RTS transmitters can be taught-in. Up to 3 sensors can be taught-in. 2 my-positions teachable. With sun automation (shutter ergonomics as with Oximo RTS). With fixed connection wires for switches/buttons.

Operating voltage: 230 V - 50 Hz, 120 V - 50 Hz
Switching current: Max. 3 A
Operating temperature: -20 to 55 °C
Protection class: IP 20
Radio frequency: 433.42 MHz
Dimensions (W x H x D): 45 x 41 x 19 mm
EAN: 3660849509071.
