Siemens Switch disconnector 3-pole
Delivered between Wed, 8.4. and Mon, 13.4.
8 pieces in stock at third-party supplier
8 pieces in stock at third-party supplier
Supplied by
Distrelec CH
free shipping
Colour5
Product details
Number of poles: 3
Current max: 25 A
Mounting type: Panel mounting
Power: 9.5 kW
Protection class: IP65
Padlock option: Yes
Operating voltage: 690 V AC
Electrical phases: 3
Switching capacity: 6000 V
Length: 49 mm
Width: 49 mm
Depth: 74 mm
Connection type: Screw mounting
CE. Switch disconnector SENTRON LD, 48x48 mm. Main and emergency stop switch. Actuating element in black or red/yellow (emergency stop). Front plate 48x48 mm. Four-hole or central hole mounting. Version with or without N-conductor contact. Lockable in 0-position with a maximum of 3 padlocks. Protection class front IP65.
Colour | Red |
Switch + button type | Switch disconnector |
Width | 49 mm |
Item number | 9729535 |
Manufacturer | Siemens |
Category | Buttons + Switches |
Manufacturer no. | 3LD21500TK13 |
Release date | 24.9.2018 |
Colour | Red |
Exact colour description | Red, Yellow |
Switch + button type | Switch disconnector |
Number of poles | 3x |
Nominal voltage | 690 V |
Nominal current | 25 A |
Max. Switching capacity | 9500 W |
Protection type (IP code) | IP65 |
Country of origin | China |
Manufacturer commitment | RE100, SBTi |
CO₂ emissions | 95.84 kg |
Climate contribution | CHF 2.28 |
Smart home | Not compatible |
Items per sales unit | 1 pcs. |
Length | 110 mm |
Width | 49 mm |
Height | 66 mm |
