Schneider Electric Front element

Schneider Electric Front Element, Black ZB4BP27

Manufacturer: Schneider Electric
Description: Front element, black for push button D22mm
Type: ZB4BP27
Button Color: Black/White/Red
Number of Command Positions: 1
Lens Shape: Round
Hole Diameter: 22.5 mm
Button Shape: High
Suitable for Lighting: No
With Protective Cover: No
Labeled: No
Latch Function: No
Push Button: Yes
With Front Ring: Yes
Material of Front Ring: Metal
Front Ring Color: Black
Protection Class (IP), Front Side: IP66
Protection Class (NEMA), Front Side: Other

Additional Details:
Front element for Harmony ZB4 push button. Black front, black metal bezel, unlabeled. Dimensions (WxHxD) 30x30x35 mm, mounting diameter 22 mm. Mechanical lifespan of 10,000,000 cycles. Round head shape, standard. With high vibration resistance and chemical resistance, ambient temperature -40 to +70 degrees C. The modular metal program with 22mm installation size combines easy installation, efficiency, and modern design. Certifications listed according to UL, LROS, DNV, GL, BV, CSA, RINA. Product standards according to CSA C22.2 No 14, EN/IEC 60947-5-5, EN/IEC 60947-5-4, UL 508, JIS C 4520, EN/IEC 60947-1, EN/IEC 60947-5-1.
