Schneider Electric 3 pole NO coil contactor,115A 24Vdc

Ratings
Delivered between Tue, 14.4. and Thu, 16.4.
Only 3 pieces in stock at third-party supplier
Supplied by
Conrad CH
free shipping

input voltage2

Product details

Area: TeSys D
Series: LC1D
Number of Poles: 3
Coil Voltage: 12 V DC
Rated Contact Current: 25 A
Rated Contact Voltage: 690 V AC
Contact Configuration: 3 NO Contacts
Number of Auxiliary Contacts: 2
Power: 5.5 kW
Connection Type: Screw Mounting
Length: 77 mm
Width: 45 mm
Maximum Operating Temperature: +60 °C

UL and CSA certified. Contactors with the suffix BL accept auxiliary contact blocks for front mounting (only the 2-contact version) and do not accept side-mounted contacts. 3-pole contactors, DC-controlled. Integrated coil fault suppression. 3 NO poles. Auxiliary contact configuration: one NO, one NC. Closing switching time: 12 to 22 ms. Opening switching time: 4 to 19 ms.

Key specifications

Relay type
Power contactor
input voltage
12 V
Electric current output
25 A
Output current type
DC
Number of poles
3x

General information

Item number
9722054
Manufacturer
Schneider Electric
Category
Relays
Manufacturer no.
LC1D12JD
Release date
24.9.2018

Relay properties

Relay type
Power contactor
input voltage
12 V
Electric current output
25 A
Output current type
DC
Switching function
Normally open
Number of openers
1x
Number of closers
3x
Number of poles
3x
Max. Switching capacity
5.50 kW

Smart home features

Smart home
Not compatible

Origin

Country of origin
France

Voluntary climate contribution

CO₂ emissions
29.26 kg
Climate contribution
CHF 0.70

Product dimensions

Length
95 mm
Width
45 mm
Height
77 mm
Weight
485 g

30-day right of return
24 Months Warranty (Bring-in)
