CHF42.90
Arctic W1-3d
Wall, 32"
Questions about Arctic W1-3d
What would you like to know?
0 questions and answers
The mount is not completely lockable. The integrated gas lift technology allows the monitor to be pulled up and pushed away smoothly and also allows vertical freedom of movement, but it cannot be fixed rigidly but can be adjusted in height with an Allen screw. By means of Allen screws, the joints can be tightened slightly so that the monitor has a smooth adjustment.
yes, everything you need is included for wall mounting
digitec
7 months ago
Helpful answer
The arm of the Arctic W1-3D monitor mount cannot be easily detached from the wall plate and reattached without disassembling the entire mount. The mount is designed to be permanently attached to the wall and there is no function that allows the arm to be removed without disassembling the wall plate. If you want to remove the monitor regularly, this may not be the best option for your needs.
Automatically generated from the .
Helpful answer
if the throttle arm is correctly adjusted (with the Allen key) it will stop in any position is a somewhat time-consuming trial and error whether more + or -
Helpful answer
Depends on the width of the column, but theoretically no problem.
Helpful answer
The mount is really stable and seems completely unimpressed by the 6kg of my 32". The specified payload is 8kg. I assume that the 8.1kg of your screen should not be a problem.
It is important that the bracket is mounted vertically. Otherwise the function is limited. For example, the horizontal swivel has too little resistance to hold the monitor in position if this swivel axis is not aligned horizontally. That is, it will move in the left-right direction like a pendulum to the lowest point. To mount the monitor correctly on a sloping wall, a wedge would be needed to compensate for the slope.
Yes, the height can be adjusted at any time. Just remember that changing the height also changes the distance between the monitor and the wall (if the arm is extended). The distance between the back of the monitor and the wall is maximum 60 cm.
This arm seems to be able to move up to 60cm away from the wall.
Hello The bracket is attached to the oval part on the wall with screws: See https://www.youtube.com/watch?v=5RoLlY13_ds Greetings
Helpful answer
I couldn't measure it directly because I use the wall mount as a tablet board, but I assume it's 8 cm. But you are welcome to check with the manufacturer: https://www.arctic.de/w1-3d. Many greetings.
Helpful answer
I totally agree with you, there is no USB hub.
If the question, in relation to the wall mount (drill hole) this is aligned with the centre of the screen when the arm is centred? Then yes it is possible, but only if the bracket is fixed much lower or higher than the screen, so as to form a more open (isosceles) triangle. In the case where the screen mount is almost horizontal, there is an offset from the centre of about 15cm.
Helpful answer
We can move the monitor approx. 65 cm away from the wall during our installation.
Yes, if you mean turning the screen upside down. It can actually do everything like the w1b plus the height is adjustable.
Helpful answer
Approx. 16 cm high and approx. 6.5 cm at the widest point at the bottom.
Helpful answer
Yes, I had everything...
The hole spacing is 10×10cm, so you can put anything on it. The question is simply the weight.
I have hung a 34" monitor on it... you can no longer see the arm. The distance remains about 10 cm.
Helpful answer
As far as I could measure, it is 40cm.
Helpful answer
The gas spring on the arm can be adjusted to the actual weight of the monitor. If you stay under the maximum weight, no problems should occur.
Helpful answer
12 x 12 cm overall size holes 10x10 / 7.5x7.5cm
Gemäss Anleitung (http://support.arctic.ac/index.php?p=w1-3d&lang=de) bis zu 60cm.
27 of 27 questions
