Purecrea 56x56x76mm Stepper Motor Nema 23 v 4.2A 1.8Nm
MotorDelivered between Fri, 4.7. and Mon, 7.7.
More than 10 pieces in stock at third-party supplier
More than 10 pieces in stock at third-party supplier
Supplied by
free shipping
Product details
This powerful stepper motor is perfect for 3D printers, CNC machines or simply for mechanical Arduino projects. If you want to operate the stepper motor with the Arduino, we recommend buying a TB6600 or HY-DIV268N-5A driver.
Recommended accessories:
Purecrea TB6600 compatible stepper motor driver 4A
Purecrea HY-DIV268N stepper motor driver 5A
Technical Details:
Model: 57H1876-420-8-21B
Shaft length: 20mm
Shaft diameter: 8mm
Step angle: 1.8
Current consumption: 4.2A / phase
Maximum torque: 1.8 Nm
Connection cable length: 50cm
Size: 42 x 42 x 60mm
Weight: 1063g
Scope of delivery:
1x 56x56x76mm stepper motor Nema 23 57H1876 4.2A 1.8Nm.
Engine type | Step motor |
Item number | 38771641 |
Manufacturer | Purecrea |
Category | Robotics module |
Release date | 25.9.2023 |
Module type | Motor |
Engine type | Step motor |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Scope of delivery | 1x 56x56x76mm stepper motor Nema 23 57H1876 4.2A 1.8Nm |
Length | 56 mm |
Width | 56 mm |
Height | 76 mm |
Weight | 1063 g |
Specifications may include unverified machine translations.
