ēlo 1903LM (19 inch) pixel multitouch
1280 x 1024 pixels, 19"6 items in stock at supplier
Product details
The Elo 03 series touch displays are designed to meet the specific requirements of the healthcare sector. They comply with the European standard EN 60601-1 for medical electrical devices and are protected against dust and liquid ingress according to IP54. Another advantage for hygiene is the seamless and frame-free design: the surface can be cleaned quickly and thoroughly. The monitors are available in four different screen sizes: 19'', 22'', 24'', and 27''. Modern PCAP technology offers up to 10 simultaneous touch points. This makes the 03 series valuable not only in staff and patient rooms but also as information displays in the clinic lobby or pharmacy. The monitors impress with excellent image quality and respond to touches with a bare finger, making them perfect for encouraging interaction from visitors and customers. Thanks to VESA compatibility, there are various mounting options available – such as on a swivel arm or on the wall.
Monitor type | PC Monitor |
Display resolution | SVGA |
Screen technology | LCD |
Refresh rate | 70 Hz |
Video connections | HDMI (1x) |
Monitor equipment | Integrated USB hub, Touch screen |
Documents | |
Item number | 17747917 |
Manufacturer | ēlo |
Category | Monitor |
Manufacturer no. | E658586 |
Release date | 8.7.2021 |
External links |
Colour | White |
Exact colour description | White |
Monitor type | PC Monitor |
Display size (inches) | 19" |
Screen size (cm) | 48 cm |
Image resolution | 1280 x 1024 pixels |
Display resolution | SVGA |
Screen technology | LCD |
Panel technology | TFT |
Refresh rate | 70 Hz |
Aspect ratio | 5:4 |
Screen surface | Anti-glare |
Contrast ratio | 1000 :1 |
Response time (grey-to-grey) | 14 ms |
Brightness | 225 cd/m² |
Viewing angle (H) | 178° |
Viewing angle (V) | 178° |
Monitor equipment | Integrated USB hub, Touch screen |
Touch | Multi-touch |
VESA wall mount | 100 x 100 mm |
Video connections | HDMI (1x) |
HDMI version | USB 1.0 |
Exact USB ports | USB-C 4 (1x) |
Audio Connections | Headphone output (1x) |
Power consumption | 18 W |
Power consumption (standby) | 0.79 W |
Energy efficiency class | F |
CO₂-Emission | |
Climate contribution |
Scope of delivery | HDMI, USB, VGA |
Width | 429.60 mm |
Length | 193.40 mm |
Height | 527 mm |
Weight | 6.30 kg |
