Littelfuse Class-T fuse 125A
Delivered Tue, 1.7.
Only 4 items in stock at third-party supplier
Only 4 items in stock at third-party supplier
Supplied by
free shipping
Product details
Features: Extremely current-limiting, compact design, 200 kA breaking capacity.
Applications: Protection of variable speed drives, power conversion devices (inverters, rectifiers, UPS), power supplies, and power distribution units, compact mains switches.
Technical data: Rated current 125A, max. voltage 125VDC, total length 62mm, diameter 27mm, fixing hole diameter 8.7mm (M8), blade width 22.2mm, blade thickness 4.8mm.
Data sheet: Class T Littelfuse, voltage 125VDC, total length 62mm, diameter 27mm, mounting hole diameter 8.7mm (M8), blade width 22.2mm, blade thickness 4.8mm.
Data sheet: Fuses Class T Littelfuse.
Item number | 49727991 |
Manufacturer | Littelfuse |
Category | Solar energy equipment |
Release date | 25.9.2024 |
Material group | Metal |
Material | Stainless steel |
Electric current output | 125 A |
CO₂-Emission | |
Climate contribution |
Items per sales unit | 1 x |
Length | 6.20 cm |
Specifications may include unverified machine translations.
