Gude Expert Power Control NET 8x Rev.3-Rear (19.07.1878)

The Remote Power Switch Expert Power Control NET 8x Rev.3 allows for the switching on and off of electrical devices via a TCP/IP network and a serial connection. To set it up, the Expert Power Control NET 8x Rev.3 is simply connected to the power supply and the desired network. Once a free IP address is assigned to the Expert Power Control NET 8x Rev.3, each of the eight power ports (max. 10 A) can be controlled from any computer on the same network using a web browser. The Expert Power Control NET 8x Rev.3 offers the option to use SNMP and Syslog. Additionally, access to the device can be restricted through IP access control (IP-ACL) and an HTTP password. Power ports can be switched via a web interface/SNMP or using buttons on the device. Protocols: HTTP, DHCP, SNMP (v1, v2c, Traps), Syslog. Network: 10 Mbit / 100 Mbit. 8-channel watchdog ICMP or TCP, adjustable pings. Power measurement (current / peak over time) and display.
