Quantity discount

Goobay GHMT-certified CAT 8.1 patch cable, S/FTP PiMF, grey

S/FTP, CAT8.1, 1 m
Save CHF0.80 CHF6.30/1m
1Ratings
BrandMore from Goobay
Delivered between Wed, 15.4. and Sat, 18.4.
More than 10 pieces in stock at supplier
Free shipping starting at 50.–

Length5

Product details

Only in combination with the GHMT-certified components listed below is the perfect functionality of this patch cable for CAT 8.1 cabling routes guaranteed. The transmission properties were tested in the 2-connector channel over a predefined transmission distance of 24 m in accordance with the specifications for Class I up to 2 GHz according to ANSI/TIA-568.2-D 2018-09: 2 Connector Channel Copper, Class I up to 2 GHzGHMT Type Approval Balanced cord: Wentronic GmbH CAT 8 patch cordPart no.: CAT 8.1 - 1 m S/FTP PiMF GreyCertified patch cables: 61091, 61092, 61093, 61094, 61095, 61102, 61103, 61104, 61105, 61106, 61113, 61114, 61115, 61116, 61117Certified installation cables: 61126, 61127, 61128Certified keystone coupler: 61136, LAN cable of 1 m length supports 25GBase-T and 40GBase-T Ethernet networks 40-gigabit capable and is backward compatible to 10BASE-T, 100BASE-TX and 1000BASE-T, , GHMT-certified for a transmission distance of 1x 24 m laying cable plus 2x 3 m patch cord in 2-Connector Channel 8.1 standard Class I with an operating frequency of up to 2 GHz, , ,.

Key specifications

Patch cable type
Copper cable
Contact assignment
straight

General information

Item number
24073977
Manufacturer
Goobay
Category
Network cables
Manufacturer no.
61115
Release date
20.3.2023
External links
Manufacturer's site (de)

Colour

Cable colour
Grey

Material

Material
Copper, Low Smoke Zero Halogen (LSZH), Polyvinyl chloride (PVC)
Material of the isolation
LSZH, PVC

Cable properties

Connection A
RJ45
Connection B
RJ45
Cable Application
Network
Cable design
Flat
Plug type
Gold-plated contacts
Cable connection
Connection (m/m)
American Wire Gauge (AWG)
26
Frequency
2000 MHz
Temperature range
0° - 20° C

Patch cable properties

Patch cable type
Copper cable
Patch cable Features
Halogen-free

Twisted-pair cable properties

Cable category
CAT8.1
Contact assignment
straight
Shield
S/FTP

Origin

Country of origin
China

Voluntary climate contribution

CO₂ emissions
5.39 kg
Climate contribution
CHF 0.13

Scope of delivery

Items per sales unit
1x
Scope of delivery
GHMT-certified CAT 8.1 patch cable, Grey, S/FTP (PiMF)

Product dimensions

Diameter
6.20 mm
Length
1 m
Width
6.20 mm
Depth
6.20 mm

Package dimensions

Length
17 cm
Width
14.50 cm
Height
2.80 cm
Weight
47 g

30-day right of return
24 Months Warranty (Bring-in)
