Finder FIND load relay

Three-pole SSR relay with a hockey puck design, suitable for mounting on a switch cabinet panel or heat sink. Input voltage is 24 V DC, featuring 3 normally open contacts rated for 25 A, with an inrush current capability of up to 300 A for 10 ms. The switching load voltage range is from 24 to 660 V AC, designed as an instantaneous value switch. The thermal power at nominal current is 90 W, and the periodic peak blocking voltage is 1600 Vpk. The residual current in the off state at nominal voltage is 10 mA. It has a dielectric strength of 4 kV from input to output. The ambient temperature range is -30 to +80 °C, and the relay protection class is IP 20. This version includes an LED. Dimensions are 105 mm in length, 78 mm in width, and 38 mm in height.
