Eaton SPCT2-460

Eaton surge arrester SPCT2-460

Manufacturer: Eaton
Designation: Surge arrester insert, 460VAC, 20kA
Type: SPCT2-460
Mains form DC: No
Mains form IT: No
Mains form TN: Yes
Mains form TN-C: No
Mains form TN-C-S: No
Mains form TT: No
Mains form other: Yes
Rated leakage impulse current (8/20): 20 kA
Max. leakage current (8/20): 40 kA
Rated voltage AC: 460 V
Rated voltage DC: 0 V
Maximum continuous voltage AC: 460 V
Maximum continuous voltage DC: 0 V
Max. PV voltage: 0 V
Protection level: 2.2 kV
Protection level L-N: 0 kV
Protection level N-PE: 0 kV
Max. overcurrent protection overcurrent protection device stub wiring (fuse): 0 A
Max. overcurrent protection device V-wiring (fuse): 125 A
Short-circuit strength (Isccr): 0 kA
Integrated short-circuit protection: No
Integrated short-circuit protection selective to fuse gG: 0 A
Integrated back-up fuse: No
Leakage current-free: No
Mounting type: On base element
Size: 1 TE
Max. conductor cross-section rigid (one-piece): 0 kV
Max. conductor cross-section rigid (solid/multistranded): 0 mm²
Max. conductor cross-section flexible (fine-stranded): 0
Max. conductor cross-section flexible (flexible): 0 mm²
With remote signalling contact: No
Signalling on the device: Optical
Test class type 2: Yes
Protection class (IP): IP20

Eaton surge arrester SPCT2-460: Further details
For protection of consumer installations against transient overvoltages caused by indirect lightning strikes and switching operations, test class II according to IEC 61643-1+A1, SPD-type T2 according to EN 61643-11, auxiliary switch SPC-S-HK can be attached for remote signalling, can be interconnected with all Xtra Combinations switchgear.
