Eaton 9PX 2200i RT2U Netpack Li-Ion
2200 VA, 2200 W, Online double converter UPSProduct details
Eaton 9PX 2200i RT2U Netpack Li-Ion The Lithium-Ion UPS 9PX features an extended battery life of 8-10 years, compared to the usual 3-5 years for VRLA batteries. With its online double-conversion topology, the 9PX continuously monitors power quality and regulates both voltage and frequency. The internal bypass allows for continued operation even in the event of a device failure. A maintenance bypass is also available to facilitate easy replacement of the UPS. Smaller form factor: The size of the battery extension has been reduced to 1U. The graphical LCD display provides a quick overview of the UPS status and measurements. Enhanced configuration options are also available. The Energy Star-rated 9PX Lithium-Ion helps reduce energy and cooling costs thanks to its outstanding efficiency. With the option for rack or tower installation, the 9PX represents the most compact solution with up to 3000 W in just 2U. All models come with the necessary hardware for tower or rack mounting.
Model | 19" rack |
Scope of application | Network cabinet, Server room |
Plug type | C13, C19, C20 |
Battery type | Li-ion |
Operating time at full load | 11 min |
Item number | 21186826 |
Manufacturer | Eaton |
Category | UPS |
Manufacturer no. | 9PX2200IRTN-L |
Release date | 14.6.2022 |
UPS type | Online double converter UPS |
Power output | 2200 W |
Output power capacity | 2200 VA |
Model | 19" rack |
Rack height units | 2 U |
UPS protection functions | Overvoltage protection |
Scope of application | Network cabinet, Server room |
Plug type | C13, C19, C20 |
USB ports | USB-A |
Data ports | RS-232 (1x) |
Input voltage | 176 V, 276 V |
output voltage | 200V, 230 V, 240V |
Input frequency | 40 / 70 Hz |
Efficiency full load | 93.50% |
Maximum operating temperature | 40 °C |
Operating temperature | 0 - 40 °C |
Operating humidity | 0% - 96% |
Max. noise level | 40 dB |
Battery category | Industry battery |
Battery | Rechargeable battery |
Battery type | Li-ion |
Voltage | 12 V |
Capacity | 9 Ah |
Operating time at full load | 11 min |
Operating time at half load | 22 min |
Country of origin | China |
Manufacturer commitment | SBTi |
CO₂ emissions | 0.31 kg |
Climate contribution | CHF 0.11 |
Scope of delivery | Cable set, Mac OS, Management Software OS: Windows, Netwerk-M2 network card, UPS |
Height | 86.50 mm |
Weight | 25 kg |
Width | 440 mm |
Length | 605 mm |
