The Dell PowerEdge R550 is a powerful rack server designed for businesses that prioritize flexibility and efficiency. Equipped with a 3rd generation Intel Xeon Silver 4309Y processor, this server delivers high processing power and is ideal for a variety of applications. With a height of 2U and the capability to install up to 8 hard drives, the R550 provides a scalable storage solution that meets the needs of growing companies. The pre-installed DELL PERC H755 RAID controller ensures reliable data storage and backup. Additionally, the server features a dual power supply configuration for added redundancy and reliability. The PowerEdge R550 is therefore an excellent choice for businesses seeking a robust and customizable server solution.
Number of rack units | 2 U |
Processor family | Xeon Silver |
Processor type | Intel Xeon Silver 4309Y |
Max. number of hard disks | 8 |
Number of processors | 1 x |
RAM | 16 GB |
Operating system | No operating system |
Item number | 40395457 |
Design | Rack Server |
Number of rack units | 2 U |
Processor family | Xeon Silver |
Processor type | Intel Xeon Silver 4309Y |
Number of processors | 1 x |
Number of processor sockets | 2 x |
Clock frequency | 2.80 GHz |
Number of threads | 16 |
Number of processor cores | 8 -Core |
Max. turbo clock rate | 3.60 GHz |
Max. TDP | 105 W |
L3 Cache | 12 MB |
Socket | LGA 4189 |
Memory type | DDR4-RAM |
Max. memory slots | 16 |
Memory configuration | 1 x 16GB |
RAM | 16 GB |
Max. RAM | 1024 GB |
RAM speed | 3200 MHz |
RAM error correction | ECC |
RAM buffer | Buffered |
RAID configuration | 0, 1, 10, 5, 50, 6, 60 |
Possible raid configuration | 0, 1, 10, 5, 50, 6, 60 |
Mass storage controller type | SAS, Serial ATA-150 |
Max. number of hard disks | 8 |
Storage capacity | 480 GB |
Form factor | 3.5" |
Interface | SATA |
Interface version | SATA III |
Hard disk additional functions | Hot plugging |
Expansion slot | PCI Express x16 (1x), PCI Express x8 (1x) |
PCI express version (max.) | 4 |
USB ports | USB-A |
Exact USB ports | USB-A 3.0 (1x) |
Connectivity | LAN |
Network connections | RJ45 (2x) |
Ethernet controller | Broadcom 57412 |
Ethernet controller brand | Broadcom |
Max. port speed | 10000 Mbit/s |
Hardware interface | Ethernet |
Video connections | VGA (2x) |
Optical drive type | No drive |
Operating system | No operating system |
Processor design | 64-bit |
Number of power supply units | 2 x |
Power | 1100 W |
input voltage | 100 - 240 V |
Max. number of power supply units | 2 |
Manufacturer commitment | RE100, SBTi |
Manufacturer compensation | According to RE100, the manufacturer Dell fully compensates for its energy consumption, leading to a reduction in emissions. |
CO₂-Emission | |
Climate contribution |
Length | 721.69 mm |
Width | 482 mm |
Height | 86.80 mm |
Weight | 24.80 kg |
