Deepcool AK620

160 mm
41Ratings
BrandMore from Deepcool
Test reportsVery good based on 2 tests
Delivered between Thu, 26.3. and Sat, 28.3.
2 items ordered
free shipping

Colour4

Product details

DeepCool AK620. Type: Cooler, Fan diameter: 12 cm, Rotational speed (min): 500 RPM, Rotational speed (max): 1850 RPM, Noise level (high speed): 28 dB, Maximum airflow: 68.99 cfm, Bearing type: Fluid Dynamic Bearing (FDB). Width: 129 mm, Depth: 138 mm, Height: 160 mm. Product colour: Black.

Key specifications

Socket
AM3, AM3+, AM4, FM1, FM2, FM2+, LGA 1150, LGA 1151, LGA 1155, LGA 1200, LGA 1700, LGA 2011, LGA 2011-v3, LGA 2066
Diameter
120 mm
Number of fans
2x
Airflow
68.99 m³/h
power connector
4-pin PWM
Height (with fan)
160 mm

General information

Item number
20851663
Manufacturer
Deepcool
Category
CPU coolers
Manufacturer no.
R-AK620-BKNNMT-G
Release date
12.5.2022
Sales rank in Category CPU coolers
117 of 1080
External links
Manufacturer's site (de)

Colour

Colour
Black
Exact colour description
Black

Cooler properties

CPU cooler design
Dual Tower
Socket
AM3, AM3+, AM4, FM1, FM2, FM2+, LGA 1150, LGA 1151, LGA 1155, LGA 1200, LGA 1700, LGA 2011, LGA 2011-v3, LGA 2066
Supported fan sizes
120mm

Heat sink properties

Number of heatpipes
6
Diameter heat pipe
6 mm
Materials radiator core
Copper
Material cooling fins
Aluminium

Fan dimensions

Diameter
120 mm

Fan properties

Number of fans
2x
Max. Speed
1850 RPM
Airflow
68.99 m³/h
Static pressure
21.48 Pa
Max. noise level
28 dB
LED colour
without LED

Connections

power connector
4-pin PWM

Power supply

Power consumption
1.44 W
Voltage
12 V

Scope of delivery

Scope of delivery
Fan

Origin

Country of origin
China

Voluntary climate contribution

CO₂ emissions
182.26 kg
Climate contribution
CHF 3.60

Product dimensions

Height (with fan)
160 mm
Weight
1460 g

Package dimensions

Length
23 cm
Width
16 cm
Height
20 cm
Weight
1.73 kg

30-day right of return
24 Months Warranty (Bring-in)
3 additional offers

Compare products

Goes with

Reviews & Ratings

Warranty score

How often does a product of this brand in the «CPU coolers» category have a defect within the first 24 months?

Source: Digitec Galaxus
  • 6.Thermaltake
    0.3 %
  • 9.Arctic
    0.4 %
  • 9.Deepcool
    0.4 %
  • 11.Cooler Master
    0.5 %
  • 12.Alpenföhn
    0.6 %

Warranty case duration

How many working days on average does it take to process a warranty claim from when it arrives at the service centre until it’s back with the customer?

Source: Digitec Galaxus
  • 1.Arctic
    0 days
  • 1.be quiet!
    0 days
  • 1.Deepcool
    0 days
  • 1.Noctua
    0 days
  • 1.Thermalright
    0 days

Return rate

How often is a product of this brand in the «CPU coolers» category returned?

Source: Digitec Galaxus
  • 11.LC-Power
    4.6 %
  • 11.Noctua
    4.6 %
  • 13.Deepcool
    5.7 %
  • 14.Dynatron
    5.9 %
  • 15.Jonsbo
    6.8 %
Source: Digitec Galaxus

Translation: machine translated
Overall ratingVery good95/100
Very good94/100
Basic TutorialsSingle testReleaseFebruary 2023

The DeepCool AK620 looks classy, is easy to assemble, strong and really affordable for its design and performance. It doesn't offer much room for criticism.

This test report belongs to a different type: AK620 WH (157 mm)
Very good95/100
gamezoom.netSingle testReleaseSeptember 2022
  • PositiveClean and high-quality workmanship (heat sink and fan)
  • Positivenoble design
  • PositiveVery good cooling capacity
  • PositiveTwo powerful and quite quiet PWM fans included in the scope of delivery
  • PositiveSafe and simple assembly
  • PositiveHigh Ram compatibility
