Cyberpower OL3000ERTXL2U

3000 VA, 2700 W, Online double converter UPS
Delivered between Thu, 10.9. and Wed, 16.9.
9 pieces in stock at supplier
free shipping

Product details

The CyberPower OL3000ERTXL2U ensures high-quality power protection for IT devices, servers, workstations, NAS/storage devices, telecommunications equipment, network devices, security and emergency systems, as well as surveillance systems.

This UPS features an online double-conversion topology for uninterrupted power supply, with an additional ECO mode that provides an energy-saving option to reduce energy costs.

The intelligent battery management system checks the battery through internal resistance measurement, allowing it to detect aging batteries and prompt replacement before failure. The battery compartment design with hot-swappable battery packs enables easy maintenance without downtime. This generator-compatible UPS includes an emergency power off (EPO) input, essential for safety systems, which allows the UPS to be de-energized immediately in case of an emergency.

To extend battery life, the UPS utilizes Smart Battery Management (SBM), which enhances the battery charging process, prolongs battery lifespan, and thereby achieves lower total operating costs.

Through the USB interface or the optionally available network card, the free downloadable management software PowerPanel Business automatically communicates with the computer and safely shuts down the system during a power outage. It also allows users to schedule shutdowns and perform self-diagnostics while monitoring energy consumption values and approximate backup time.

Electrical safety

Due to its high performance, this device requires a 16 Ampère socket (type 23). If no suitable wall socket is available, the conversion must be carried out by an authorised installer.

Key specifications

Model
Desktop
UPS protection functions
Overvoltage protection
Scope of application
Server room
Plug type
C13C19C20
Operating time at full load
3 min
Operating time at half load
9 min
Battery type
Lead–acid battery

General information

Item number
10170294
Manufacturer
Cyberpower
Category
UPS
Manufacturer No.
OL3000ERTXL2U
Release date
29.11.2018

UPS properties

UPS type
Online double converter UPS
Power output
2700 W
Output power capacity
3000 VA
Model
Desktop
Rack height units
2 U

UPS functions

UPS protection functions
Overvoltage protection

Application range

Scope of application
Server room

Connections

USB ports
USB-A
Data ports
RS-232 (1x)

Operating conditions

Maximum operating temperature
40 °C
Operating temperature
0 - 40 °C

Mains supply properties

Plug type
C13C19C20
Input voltage
190 - 300 V
Min. input voltage
190 V
Max. input voltage
300 V
Max. output voltage
240 V
Max. input current
15 A
Input frequency
40 / 70 Hz
overvoltage protection
1335 J
Efficiency full load
93%
Efficiency battery operation
93%

Battery properties

Operating time at full load
3 min
Operating time at half load
9 min
Battery category
Industry battery
Battery
Battery
Battery type
Lead–acid battery
Battery size
Device specific
Number of cells
12x
Battery weight per cell
2000 g
Capacity
9 Ah
Power capacity
108 Wh
Battery voltage
12 V
Charging time
5 h

Origin

Country of origin
China

Voluntary climate contribution

CO₂ emissions
180.74 kg
Climate contribution
CHF 4.29

Scope of delivery

Scope of delivery
PowerPanel® Business EditionSerialUSB cable
Items per sales unit
1x

Product dimensions

Height
88 mm
Weight
32 kg
Width
433 mm
Length
600 mm

Package dimensions

Length
88 cm
Width
56 cm
Height
23 cm
Weight
39.50 kg

30-day right of return
24 Months Warranty (Bring-in)
