Aim TTi FX100TP Labornetzgerät, einstellbar 0 - 42 V 1 mA - 6 A 246 W fernsteu

Triple Output PowerFlex Autorange Laboratory Power Supply

Flexible Power
The heart of the FX series is Aim-TTi's advanced PowerFlex technology. It features intelligent automatic range adjustment that dynamically adapts the operating range within the 105 W channel power. This ensures optimal efficiency and performance, allowing users to precisely tailor the power to the application requirements.

High Setting Resolution
For applications requiring the highest accuracy and resolution, up to 5-digit setting and measurement functions for voltage and current are available. The resolution is 1 mV/1 mA.

Compact and Lightweight Design
The FX models are specifically designed for your workspace. Their compact footprint (200 x 140 x 300 mm (W x H x D)) ensures they do not take up unnecessary space on your workbench or shelf. The low-pressure fan cooling system keeps the units cool without increasing noise levels.

Unmatched Versatility and Control
The FX series redefines user interaction with its intuitive 4.3-inch color touchscreen, enabling precise adjustments with just a fingertip. For those who prefer a tactile experience, the series also offers live adjustment via rotary knobs for a hands-on feel.

Voltage Tracking
All outputs are fully independent and isolated. However, it is possible to configure the power supply so that the voltage at output 2 automatically follows the voltage at output 1.

Multi On/Off
Many circuits can be damaged if one voltage rail is present without the other. In addition to the individual on/off buttons for the outputs, there is a multi on/off function that allows one or more outputs to be turned on or off with a single button press.
