Product details
ABL Energy Cube 4E 1561
Manufacturer: ABL
Designation: Energy Cube 4xSchuko, IP44
Type: 4E 1561
Number of Schuko sockets: 4
Protection: without RCD
Material of the housing: plastic
Power supply/connection option: 1 line (branch line)
Handling: suspendable
Protection class (IP): IP44
Military version: no
Color: gray
The suspendable energy cube is pre-wired and ready for connection. Each energy cube, including the built-in devices, is individually tested according to EN 61439-3. The entire energy cube is splash-proof according to IP 44. The housing is made of polyamide plastic. This high-quality plastic is particularly characterized by its excellent strength and toughness. The housing color is light gray (electrical gray). Without built-in components, the cube measures (HxWxD) 160 x 104 x 104 mm. The energy cube is equipped with 4 x Schuko sockets. The housing features a suspension bracket and a cable entry (gland) from above. The gland is suitable for a supply line of 3 x 1.5 mm² up to 5 x 6 mm². The outer diameter of the supply line must not exceed 19 mm. A terminal block is available for connecting the supply line. The terminal block is suitable for supply lines of 5 x 6 mm² (rigid).
Number of cans | 4 x |
mounting style | Suspendable |
Socket type | CEE 7/3 |
Area of use | Inside |
Exact colour description | Dgrey |
Item number | 20027073 |
Colour | Grey |
Exact colour description | Dgrey |
Material group | Plastic |
Material | Plastic |
Socket type | FI socket |
Socket type | CEE 7/3 |
Number of cans | 4 x |
Protection type (IP code) | IP44 |
Area of use | Inside |
mounting style | Suspendable |
connector type | Plug terminal |
Additional properties | Hangable |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Length | 10.40 cm |
Width | 10.40 cm |
Height | 19.30 cm |
Weight | 650 g |
Length | 34 cm |
Width | 15 cm |
Height | 16 cm |
Weight | 760 g |
