Best selling Lab power supplies
Here’s a ranking of the best selling Lab power supplies. To give you a quick overview, we’ve added the most important information about each product. This page always stays fresh and updates automatically.
1. Peaktech P 6227 Switched-mode power supply unit
This newly developed laboratory power supply offers an adjustable 0...60V or 0...6A DC main output with a maximum continuous power of 150W. For developers, this lab power supply offers two switchable USB outputs with their own LCD display with voltage and current values. If you use a load up to 2.5A, you can regulate the output voltage up to 60V. If you want to use a higher current up to 6A, regulate the load to a maximum of 25V. Of course, all levels in between are also adjustable, such as 30V/5A, 40V/3.7A or 50V/3A. The current and voltage setting is also done when the output is switched off. By pressing the rotary knob for current or voltage, the setting resolution can be switched fine/coarse from 1mA to 100mA or 10mV to 1V. Due to the high range of functions and the simple operation with the best price/performance ratio, this laboratory power supply is ideal for the training, hobby, developer and service area.
2. Peaktech P 6226 Switched-mode power supply unit
This laboratory power supply offers an adjustable DC voltage output of 0 - 30 V or 0 - 10 A. The current and voltage settings are made via digital potentiometers, allowing both values to be adjusted even when the output sockets are turned off. By pressing the respective rotary knob for current or voltage, the setting resolution can be switched from 10 mA to 100 mA or from 10 mV to 1 V. To ensure safe measurements, there is a button on the front of the PeakTech 6226 that is used to control the output of the voltage. The display also indicates when the output is active. With the CV and CC functions, the voltages and currents can be set to constant values that do not change when a load is connected. These features make the PeakTech 6226 a remarkable companion for any hobbyist electronics enthusiast as well as for any specialist.
3. Peaktech P 6225 A Switched-mode power supply unit
This laboratory power supply offers a variable DC voltage output of 0 - 30 V or 0 - 5 A. The current and voltage settings are made via digital potentiometers, allowing both values to be adjusted even when the output sockets are turned off. By pressing the respective rotary knob for current or voltage, the adjustment resolution can be switched from 10 mA to 100 mA or from 10 mV to 1 V. To ensure safe measurements, there is a button on the front of the PeakTech 6225 A that is used to control the output of the voltage on and off. The display also indicates when the output is active. Another notable feature is the CV and CC function of the laboratory power supply. With this function, the voltages and currents can be set to constant values that do not change when a load is connected. These features make the PeakTech 6225 A a remarkable companion for any hobbyist in electronics, as well as for any specialist.
4. Uni-T UDP3305S-E
Linear DC power supply unit. Channels: 4. 328 W. Output voltage: CH1/CH2:0~30V CH3:0~6V CH4:5V. Output current: CH1/CH2:0~5A CH3:0~3A CH4:2A. Resolution: 10mV,1mA. Setting accuracy: <0.3%+20mV <0.2%+5mA. Connectivity : USB device, RS-232, LAN, USB host, Digital I/O.
5. Joy-it JT-PS1440-C
Joy-it JT-PS1440-C Laboratory power supply, adjustable 0 - 60V, 0 - 24A, 1440W, programmable, remote controllable.
6. Peaktech P 6220 Mini -switching power supply
The PeakTech 6220 is a compact and lightweight DC power supply that impresses with its high performance and excellent price-performance ratio. Thanks to the switching power supply technology used, it ensures high power output in a small size and low weight. The output voltage is continuously adjustable via a potentiometer on the front, while the current is limited to a maximum of 2 A. The 4 mm terminal blocks allow for easy connection of individual wires as well as 4 mm banana plugs. The power cable with a Euro plug is permanently attached to the device, and it is turned on and off using the power switch on the front. This handy power supply fits on any workbench and is versatile for use in hobbies, service work, or training.
7. Joy-it JT-RD6006-C-B Laboratory power supply, adjustable 0 - 60V 0 - 6A 360W remote-controlled
Programmable laboratory power supply with a power output of 360 W. 2.4" LCD color display. Control via software using USB/WiFi. Constant voltage and constant current modes. Output voltage: 0 - 60 V. Output current: 0 - 6 A. Adjustable overcurrent and overvoltage protection, integrated RTC, NTC temperature sensor. With an output voltage range of 0 - 60 V and a power capacity of 0 - 360 W, you can tackle any type of project. The compact design and user-friendly operation make the RD6006B an excellent choice for any application. The 9 memory slots allow you to quickly and easily switch between different settings. The device can be operated via software through the USB interface. It also features various protection and limiting functions such as constant voltage operation, constant current operation, overvoltage protection, overcurrent protection, and replaceable fuses on the board.
Lab power supply
CHF229.–
Joy-it JT-RD6006-C-B Laboratory power supply, adjustable 0 - 60V 0 - 6A 360W remote-controlled
8. Uni-T UDP6720 Programmable DC Switching Power Supply 60V 100W
The UDP6720 DC power supply from UNI-T is a digital control power supply with an output range of 0-60V, 0-5A, and 0-100W. It features full digital control, high resolution and accuracy, and an overvoltage/overcurrent protection function. It is ideal for applications in electronics development, battery charging, electric vehicles, research laboratories, and educational sectors.
Recommended accessories:
1 pair of laboratory cables 32A 600V 150cm 2.5mm² banana plug 4mm
2 pieces of crocodile clip/tapping clamp 15A for 4mm banana plug
Features:
2.8-inch colour LCD display
List and delay functions
Remote compensation function
RS232 communication
Technical details:
Manufacturer: UNI-T
Manufacturer SKU: UDP6720
Output voltage: 0~60V
Output current: 0~5A
Output power: 100W
Load regulation: <0.01%+3mV, <0.01%+3mA
Line regulation: <0.01%+3mV, <0.1%+3mA
Programming accuracy: <0.05%+10mV, <0.2%+2mA
Readback accuracy: <0.05%+10mV, <0.1%+2mA
Noise: <2.0mVrms (voltage), <5.0mArms (current)
Setting resolution: 10mV, 1mA
Read-back resolution: 10mV, 1mA
Display: 2.8 inch LCD, 4-digit display
Interface: RS232, remote compensation
Power input: AC 110V/220V (±10%) at 50Hz/60Hz
Operating temperature: 0~45°C
Storage temperature: -20~70°C
Dimensions: 87 x 255 x 174mm
Weight: 2560g
Scope of delivery:
1x UNI-T UDP6720 programmable DC switching power supply 60V 100W.
1x power cable.
9. Voltcraft Linear laboratory power supply unit
Electronically stabilized laboratory power supply unit with separate voltage and current regulators. The current limit can be preset at the output without a short-circuit bridge. The LPS series is actively ventilated.
10. Goobay 12-V-Netzteil
The 1-A power supply is the practical power source for many small devices such as external hard drives, docking stations, scanners, phones, ISDN systems, or fax machines. Its high efficiency and low standby consumption effectively reduce energy consumption and heat generation, thereby lowering the CO2 emissions of the power supply.
The plug-in power supply with a fixed voltage is perfect as a replacement power supply for electronic devices such as TV boxes, routers, LED strips, video cameras, digital photo frames, dartboards, baby monitors, or toys. It is easy to connect and operates quietly, providing stabilized direct current at 12 V with up to 1 A.
The high efficiency ensures a low operating temperature and a long lifespan for the DC power supply. It is particularly environmentally friendly and energy-efficient due to its low standby consumption. With a wide input range of 100 V to 240 V, the power adapter (Euro plug type C, CEE 7/16) is suitable for worldwide use.
Fuses in the switching power supply protect against short circuits, overloads, overvoltage, and overcurrent. The power supply features a convenient LED operating indicator and a cable length of 1.8 m.
