Best selling Satellite accessories from Busch-Jaeger
On this page you'll find a ranking of the best Busch-Jaeger products in this category. To give you a quick overview, we've already ranked the most important information about the products for you.
1. Busch-Jaeger BNC-F
Busch-Jaeger BNC-F Socket 0262
Manufacturer: Busch-Jaeger
Description: BNC-F socket for communication adapters
Type: 0262
Composition: Basic element
Usage: Satellite
Mounting ring: yes
With dust protection: no
With flap cover: no
Outlet direction: straight
Labeling field: without labeling field
With printing: no
Mounting type: Flush-mounted
Material: Metal
Material quality: other
Halogen-free: yes
Antibacterial treatment: no
Surface protection: other
Surface finish: matte
Color: Silver
Transparent: no
Mounting type: Screw mounting
Number of modules (in modular design): 1
With sockets/couplings: no
Suitable for number of sockets/couplings: 2
With strain relief: no
Shielded sockets: no
Shielded housing: no
Terminal block: no
With lighting: no
Suitable for protection class (IP): IP20
Device width: 13 mm
Device height: 13 mm
Device depth: 21 mm
Min. depth of device box: 32 mm
Busch-Jaeger BNC-F Socket 0262: additional details
F-connector socket for installation in communication adapters 0262/xx for connecting antenna cables, e.g., for TV devices with integrated satellite tuner and satellite receiver. With screw connection.
2. Busch-Jaeger F-connector module
BNC F keystone module feed-through socket with screw connection for insertion in mounting adapter 0219/14, similar to RAL 9005. Enables simple plug and play installation of antenna cables with F connectors. Fits into standard keystone openings (14.7 mm x 19.3 mm).
3. Busch-Jaeger Insert
Busch-Jaeger insert 0230-101
Manufacturer: Busch-Jaeger
Designation: Insert
Type: 0230-101
Design: Branch box
Mounting type: Flush-mounted
Cover: Without
Connection attenuation at 860 MHz: 43.955 dB
Connection attenuation at 2150 MHz: 43.956 dB
Number of outlets: 2
Suitable for cable modem: No
Remote power supply suitable: Yes
Frequency: 4 MHz
Mounting type: Claw/screw mounting
Colour: Other
Surface protection: Metallic
Material: Other
Material quality: Other
Halogen-free: Yes
Antibacterial treatment: No
Protection class (IP): IP20
Busch-Jaeger insert 0230-101: Further details
Broadband technology 5-2,400 MHz for DVB-T, satellite, and broadband cable systems. For analogue and digital transmission. With spreader. Low installation depth, class A.
EAN: 4011395809006.
4. Busch-Jaeger Antenna dos. insert
Busch-Jaeger aerial socket insert 0232-101
Manufacturer: Busch-Jaeger
Designation: Aerial socket insert, stub
Type: 0232-101 Insert SAT, spur
Design: Spur box
Mounting type: Flush-mounted
Cover: Without
Connection attenuation at 860 MHz: 43.952 dB
Connection attenuation at 2150 MHz: 2 dB
Number of outlets: 3
Suitable for cable modem: No
Remote power supply suitable: Yes
Frequency: 4 MHz
Mounting type: Claw/screw mounting
Colour: Other
Surface protection: Metallic
Material: Other
Material quality: Other
Halogen-free: Yes
Antibacterial treatment: No
Protection class (IP): IP20
Busch-Jaeger antenna endos.-Insert 0232-101: Further details
Broadband technology 47-2,150 MHz. SAT connection designed as screwable F socket. Can be remote-fed via F socket. For DVB-T and broadband cable systems. For analogue and digital transmission. With spreader. Low installation depth, class A.
