Busch-Jaeger Antenna dos. insert

Busch-Jaeger aerial socket insert 0232-101

Manufacturer: Busch-Jaeger
Designation: Aerial socket insert, stub
Type: 0232-101 Insert SAT, spur
Design: Spur box
Mounting type: Flush-mounted
Cover: Without
Connection attenuation at 860 MHz: 43.952 dB
Connection attenuation at 2150 MHz: 2 dB
Number of outlets: 3
Suitable for cable modem: No
Remote power supply suitable: Yes
Frequency: 4 MHz
Mounting type: Claw/screw mounting
Colour: Other
Surface protection: Metallic
Material: Other
Material quality: Other
Halogen-free: Yes
Antibacterial treatment: No
Protection class (IP): IP20

Busch-Jaeger antenna endos.-Insert 0232-101: Further details
Broadband technology 47-2,150 MHz. SAT connection designed as screwable F socket. Can be remote-fed via F socket. For DVB-T and broadband cable systems. For analogue and digital transmission. With spreader. Low installation depth, class A.
