Busch-Jaeger insert 0230-101
Manufacturer: Busch-Jaeger
Designation: Insert
Type: 0230-101
Design: Branch box
Mounting type: Flush-mounted
Cover: Without
Connection attenuation at 860 MHz: 43.955 dB
Connection attenuation at 2150 MHz: 43.956 dB
Number of outlets: 2
Suitable for cable modem: No
Remote power supply suitable: Yes
Frequency: 4 MHz
Mounting type: Claw/screw mounting
Colour: Other
Surface protection: Metallic
Material: Other
Material quality: Other
Halogen-free: Yes
Antibacterial treatment: No
Protection class (IP): IP20
Busch-Jaeger insert 0230-101: Further details
Broadband technology 5-2,400 MHz for DVB-T, satellite, and broadband cable systems. For analogue and digital transmission. With spreader. Low installation depth, class A.
EAN: 4011395809006.
Item number | 21350199 |
Manufacturer | Busch-Jaeger |
Category | Satellite accessories |
Manufacturer no. | 2CKA000230A0250 |
Release date | 29.6.2022 |
Colour | Grey |
Exact colour description | Metallic |
Satellite accessory type | Plug socket |
Power supply | None |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Scope of delivery | 1 piece |
Length | 83 mm |
Width | 108 mm |
Height | 142 mm |
Weight | 100 g |
