Best Poynting products in the Network antenna category
On this page you'll find a ranking of the best Poynting products in this category. To give you a quick overview, we've already ranked the most important information about the products for you.
1. Poynting XPOL-2-5G-01
Highly reinforced, cross-polarized 5G. Radiation pattern: directional beam, 11 dBi. Antenna connection details: 2x SMA. Mounting: mast, wall. Application area of the antenna: indoor, outdoor. Purpose of the antenna: 5G/LTE/3G/GSM. Frequency band: 0.7 GHz, 0.8 GHz, 0.9 GHz, 1.8 GHz, 1.9 GHz, 2.1 GHz, 2.5 GHz, 2.6 GHz, 3.4 GHz, 3.5 GHz, 3.7 GHz, 3.8 GHz. Two cross-polarized antennas in one housing for optimal LTE performance. Weatherproof, dustproof, and vandal-resistant IP65 housing, cable length 5 m. The USL-1006420 antenna for 5G/LTE is cross-polarized and features an IP65 housing that protects it from weather, dust, and vandalism. It is suitable for both indoor and outdoor use and is also impact-resistant to IK08 standards. The antenna can be easily mounted on a wall or a mast and comes with a 5 m long connection cable with 2x SMA connectors. It is backward compatible with 2G/3G/4G/LTE antennas and is ready for 5G deployment.
2. Poynting A-XPOL-0002-V3-03
A-XPOL-0002-V3-03 - Cross-polarized, unidirectional LTE antenna
The XPOL-2-5G is Poynting's third generation of this highly popular cross-polarized (XPOL) mobile band 2x2 MIMO antenna. The antenna housing looks almost identical to that of the second generation but has been completely redesigned internally. Poynting has utilized advanced metamaterial technology, incorporating artificial magnetic conductors (AMC) and a new, patented radiator configuration that demonstrates exceptional improvements in bandwidth and gain. The radiation patterns of this antenna are exceptionally well controlled, further enhancing the antenna's performance.
The XPOL-2-5G antenna includes the newer 3400 - 3800 MHz bands, which were not covered by the V2 and is suitable for 2G, 3G, 4G, and 5G. This antenna performs exceptionally well in the following frequency bands: 698 - 960 MHz, 1700 - 2170 MHz, 2300 - 2700 MHz, and 3400 - 3800 MHz. In addition to the new bands, the gain at 1700 MHz and 2.7 GHz across the same frequency bands is about 3 dB higher than that of V2. The V2 antenna already outperformed most competitors in these areas, so this significant gain improvement showcases the advantages of the new advanced materials and innovative radiator design.
If it were a car, Poynting would have installed a completely new technological engine that produces double the power under the hood - it may look the same, but just wait until you turn on the ignition!
Antenna derivatives
Product order code (SKU): A-XPOL-0002-V3-03
Coaxial cable type: Twin HDF 195
Coaxial cable length: 10 m
Connector type: SMA (m)
Product weight: 1.73 kg
Packaging weight: 2.16 kg
Electrical data - Mobile communication
Frequency bands: 698-960 MHz; 1710-2700 MHz; 3400-3800 MHz
Gain (max.) Port 1 and 2: 9 dBi at 698-960 MHz; 10 dBi at 1710-2700 MHz;...
3. Poynting XPOL-2-5G
The XPOL-2-5G is Poynting's V3 of the third generation of this very popular cross-polarised (XPOL) mobile radio band 2x2 MIMO antenna. The antenna housing looks virtually the same as the second generation V2, but has been completely redesigned inside. Poynting has utilised advanced metamaterial technology, using artificial magnetic conductors (AMC) and a patent-pending radiator configuration that demonstrates exceptional improvements in bandwidth and gain. The radiation patterns of this antenna are exceptionally well controlled, further enhancing the antenna's performance.
The XPOL-2-5G antenna includes the 3400 - 3800 MHz bands not previously covered by the V2 and is suitable for 2G, 3G, 4G and 5G. This antenna performs exceptionally well in the following frequency bands: 698 - 960 MHz, 1700 - 2170 MHz, 2300 - 2700 MHz and 3400 - 3800 MHz. In addition, the gain at 1700 MHz and 2.7 GHz over the same frequency bands is about 3 dB higher than with V2. The V2 antenna already outperformed most competitors in these bands, so this significant improvement in gain demonstrates the benefits of the advanced materials and radiator design.
So if it was a car, Poynting installed a technology engine that produces twice the power under the bonnet - it may look the same, but just wait until you switch on the ignition.
4. Poynting 43087 - A-PUCK-0005-V2-01 black, 5-in-1 IoT motorhome camper vehicle antenna
The Poynting 43087 - A-PUCK-0005-V2-01 is a state-of-the-art 5-in-1 IoT RV camper vehicle antenna designed for a variety of applications. This robust, ultra-wideband omnidirectional antenna provides comprehensive coverage for various mobile communication standards, including 5G, LTE, 4G, 3G, and 2G, as well as Dual-Band Wi-Fi 6E. With a maximum gain of 6 dBi and a frequency range of 617 to 6000 MHz, it is ideal for use in transportation, marine, and IoT/M2M applications. The antenna is not only vandal-proof and waterproof (IP69K), but also offers versatile mounting options, making installation in different environments easy. Its compact design and integrated features make it an excellent choice for modern RVs and campers.
- 5-in-1 antenna system supporting 5G, LTE, Wi-Fi 6E, GPS, and GLONASS
- Ultra-wideband coverage from 617 to 6000 MHz
- Robust and vandal-proof with IP69K certification
- Versatile mounting options for easy installation
- Includes 2 m RKT-031 cable with SMA connector.
Network antenna
CHF114.–
Poynting 43087 - A-PUCK-0005-V2-01 black, 5-in-1 IoT motorhome camper vehicle antenna
5G, 3G, 4G, 2G, GPS, Wi-Fi, Lora
5. Poynting Antenna- 5G/LTE- Mast/Wall- A-XPOL-0024-V1-01- white- SMA M-
X-polarised, unidirectional 4x4 MIMO 5G/LTE antenna. Exceptional high-performance antenna with new advanced metamaterial technology for wideband 4x4 MIMO 5G/LTE from 617 to 4200 MHz. Maximum gain: 11 dBi. Includes a 5-meter SMA-male cable and twin HDF-195. IP65 rated with wall and pole mounting materials included.
6. Poynting Antennas - 5G/LTE - Automotive/Naval - A-MIMO-0003-V2-17-B - black - SMA (M) & RPSMA Adapter
The MIMO-3-17 is a 7-in-1 high-performance multi-frequency antenna housed in a single enclosure, featuring four cellular antennas, two Wi-Fi antennas, and one GPS/GLONASS antenna. The four MIMO antennas for 2G/3G/4G/5G cover frequency bands from 698 MHz to 2700 MHz, as well as the emerging LTE and 5G spectrum for the CBRS bands of 450 MHz and 3.5 GHz. The antenna's ultra-wideband performance allows for use across various operators and technologies. It also includes two separate dual-band Wi-Fi antennas that simultaneously support 2.4 GHz and 5 GHz with 2x2 MIMO capability. The seventh antenna is a high-performance active GPS/GLONASS system that operates down to -40 °C. The radiation patterns of all radiating elements provide an excellent balance between spherical characteristics, pattern diversity, and good radiation properties at the desired transmission height. This is a crucial criterion for the transport and marine market for which the antenna was specifically designed. Main application areas include commercial and industrial vehicles, shipping, M2M, and other IoT systems that utilize a wide range of radio technologies while remaining future-proof across the broad frequency band.
7-in-1 high-performance multi-frequency 2G/3G/4G/LTE antenna (5G ready)
4x4 MIMO LTE, 2x2 MIMO Wi-Fi, and GPS/GLONASS
Ultra-wideband, includes CBRS bands 450 MHz and 3.5 GHz
Robust and water-resistant antenna (IP 68)
Ideal for transport and shipping
Multiple mounting options for easy installation.
Network antenna
CHF280.95
Poynting Antennas - 5G/LTE - Automotive/Naval - A-MIMO-0003-V2-17-B - black - SMA (M) & RPSMA Adapter
5G
7. Poynting OMNI-214
The OMNI-214 is a powerful ultra-wideband antenna that covers all current LTE and 5G frequency bands from 617 to 3800 MHz. With 4x4 MIMO capability achieved by vertically separated radiating elements in a single radome, this antenna provides superior pattern control over the entire frequency range. Designed for urban and commercial applications, the OMNI-214 provides reliable signal reception worldwide and is future-proofed for new network technologies.
8. Poynting Antennas OMNI-A0121
This omnidirectional antenna with medium gain covers the frequency bands GSM 900, GSM 1800 / UMTS, and LTE. It is a lightweight antenna that is easy to install. It offers a cost-effective omnidirectional solution as it comes with a 5-meter long cable. The antenna is very popular among installers due to its versatile base station features. It is also ideal for Machine-to-Machine (M2M) applications that communicate over the GSM network (GPRS/EDGE/3G/HSPA/LTE).
Highlights
• Wall and mast mounting options
• Agile base station
• Lightweight
• Covers most international GSM and LTE bands
Applications
• Enables the provision of wireless services in rural and remote areas
• M2M communication (ATMs, financial data processing, telemetry, etc.)
• Extends wireless data transmission to areas with weak signals (can increase connectivity range by a factor of 3 or more)
• Poor reception of data signals (indoors or outdoors)
• Slow data transmission connection
• Unstable connection
• Increases reliability of system transmission
Package Contents
• A-OMNI-0121-V3
• M6x60mm U-bolt screw
• Econo bracket
• M6 nuts
• M6 washers
• Dowels and screws for easy installation.
9. Poynting OMNI-510-2 - A-OMNI-0510-V1-02 - Omnidirectional Wideband Ultra Low Profile Antenna
Poynting A-OMNI-0510-V1-02 - Omnidirectional Wideband Ultra Low Profile Antenna
The OMNI-510-01 antenna is purposefully designed for ultra-low profile requirements such as smart meters. This omni-directional antenna is suitable for indoor and outdoor use, typically mounted on the top or side of smart meter boxes. The OMNI-510-01 antenna is designed with installation simplicity in mind, while covering the LTE frequency bands 698 – 2700 MHz.
Features:
- Omni-directional antenna
- Wideband - covers a wide frequency band
- Easy installation, double-sided tape or screw-on
- Stylish, but robust design
- Weather resistant
M2M and IoT Application Areas:
- Smart utilities: Smart power metering, gas and water metering
- Smart buildings: Climate control, access control, security, irrigation
- Digital signage
- Smart environmental and water systems
- Warehouses and logistic systems
- Industrial factory automation and M2M systems
- Farming and agricultural M2M and IoT
Can be used with the following IoT technologies:
- Zigbee
- Z-Wave
- LoRaWAN
- Sigfox
- Wi-Fi
- Wi-Fi HaLow
- Cellular Bands (LTE/3G/2G), including LTE-M/NB-IoT
- Bluetooth
Electrical Specifications:
- Frequency band 1: 698 - 960 MHz
- Frequency band 2: 1710 - 2700 MHz
- Gain (max.): 2 dBi
- VSWR:
- Feed power handling: 10 W
- Input impedance: 50 Ohm (nominal)
- Polarisation: Linear horizontal / vertical (installation dependent)
- Cable loss: 0.45 dB/m at 900 MHz; 0.71 dB/m at 2000 MHz; 0.79 dB/m at 2500 MHz; 0.9 dB/m at 3000 MHz
- Cable: RTK-031 SMS-plug
- Cable length: 1 m
Mechanical Specifications:
- Product dimensions (L x W x D): 138 x 26 x 10 mm
- Packaging material: Poly bag
- Radome material: TPE (Thermoplastic Elastomer)
- Radome colour: Pantone Black or Cool Gray 1C (TBC)
- Mounting: Adhesive backing or screw mount
Environmental Specifications:
- Wind survival: 160 km/h
- Temperature range (operating): -40°C to +75°C
- Environmental conditions: IP68 (excluding connector)
- Operating relative humidity: Up to 98%
- Storage humidity: 5% to 95%.
Network antenna
CHF33.90
Poynting OMNI-510-2 - A-OMNI-0510-V1-02 - Omnidirectional Wideband Ultra Low Profile Antenna
10. Poynting OMNI-291-V2 - A-OMNI-0291-V2 - Omnidirectional Marine Antenna
A-OMNI-0291-V2 - Marine Omnidirectional Antenna
The OMNI-291-V2 is a high-performance ship antenna. This antenna uses a standard 1-inch (14 TPI) boat mount for simplified installation on most boat accessories. The ultra-wide frequency band covers all modern LTE operating frequencies and provides excellent symmetrical gain across all frequencies, including the 450 MHz LTE and CDMA bands commonly used for marine applications.
Higher frequencies are unaffected, and the antenna design allows Poynting to achieve superior pattern control across the entire frequency range, making the OMNI-291-V2 a true omnidirectional high-performance antenna. The OMNI291 can be used in all parts of the world and guarantees signal reception almost anywhere along the coast. Poynting achieves this through a new antenna configuration with multiple dipoles and a unique (patented) feeding network. The antenna is future-proof as it covers the 450 MHz LTE frequency, which is increasingly utilized in various regions and countries.
Features
- Omnidirectional antenna with medium gain
- The antenna is specifically designed for marine and coastal applications
- Lightweight
- UV and saltwater resistant
- Robust and weatherproof
- In the 2.4 - 2.5 GHz band, the antenna can be used as a Wi-Fi antenna
Applications
- Marine applications on yachts, boats, and ferries
- Enhanced LTE reception
- IoT and M2M
- Poor data signal reception
- Improvement of data transmission connection reliability and stability
- Wi-Fi applications
Electronic Specifications
- Frequency bands: 450–470 MHz; 690–960 MHz; 1710-2170 MHz; 2300–2700 MHz
- Gain (max): 7 dBi
- VSWR: <2.5:1 over 90% of the band
- Input power: 10 W
- Input impedance: 50 Ohm (nominal)
- Polarization: Linear vertical.
