A-XPOL-0002-V3-03 - Cross-polarized, unidirectional LTE antenna

The XPOL-2-5G is Poynting's third generation of this highly popular cross-polarized (XPOL) mobile band 2x2 MIMO antenna. The antenna housing looks almost identical to that of the second generation but has been completely redesigned internally. Poynting has utilized advanced metamaterial technology, incorporating artificial magnetic conductors (AMC) and a new patented radiator configuration that demonstrates exceptional improvements in bandwidth and gain. The radiation patterns of this antenna are exceptionally well-controlled, further enhancing the antenna's performance.

The XPOL-2-5G antenna includes the newer 3400 - 3800 MHz bands, which were not covered by the V2, and is suitable for 2G, 3G, 4G, and 5G. This antenna performs exceptionally well in the following frequency bands: 698 - 960 MHz, 1700 - 2170 MHz, 2300 - 2700 MHz, and 3400 - 3800 MHz. In addition to the new bands, the gain at 1700 MHz and 2.7 GHz across the same frequency ranges is approximately 3 dB higher than that of the V2. The V2 antenna already outperformed most competitors in these areas, so this significant gain improvement showcases the benefits of the new advanced materials and innovative radiator design.

If it were a car, Poynting would have installed a completely new technology engine that produces double the power under the hood - it may look the same, but just wait until you turn the ignition on!

Antenna derivatives
Product order code (SKU): A-XPOL-0002-V3-03
Coaxial cable type: Twin HDF 195
Coaxial cable length: 10 m
Connector type: SMA (m)
Product weight: 1.73 kg
Packaging weight: 2.16 kg

Electrical data - Mobile communication
Frequency bands: 698-960 MHz; 1710-2700 MHz; 3400-3800 MHz
Gain (max.) Port 1 and 2: 9 dBi at 698-960 MHz; 10 dBi at 1710-2700 MHz;...
