Best selling Energy monitors from Shelly
On this page you’ll find a ranking of the best Energy monitors from Shelly. To give you a quick overview, we’ve added the most important product details. This page always stays fresh and updates automatically.
1. Shelly Pro 3EM 120A
The Shelly Pro 3EM is a Wi-Fi-operated, DIN-mountable 3-phase power consumption meter with Wi-Fi, Bluetooth, and LAN connectivity. With its 1% accurate active energy measurement, the Shelly Pro 3EM can be used to monitor the consumption of all household appliances, circuits, and office devices individually. Historical data is stored for up to 60 days, with each phase having a one-minute resolution. Additionally, the scripting functionalities allow for the execution of complex scenarios and provide advanced monitoring options.
Includes 3 current transformers 120 A.
2. Shelly 3EM-63W Gen3
The Shelly 3EM-63W Gen3 (Wire Model) is an advanced three-phase energy meter specifically designed to accurately measure energy consumption in three individual phases. With a maximum load of up to 63 A and an accuracy of 99 %, this device fulfils IEC 62053-21 Class B standards. It enables real-time monitoring of power data such as current, voltage and power factor with a resolution of one minute. In addition, the Shelly 3EM-63W stores energy consumption data at hourly intervals for up to five years, enabling comprehensive analysis of energy consumption. The compact design integrates electronics and current transformer in one unit, minimising the space required on the DIN rail. Easy installation and advanced connectivity options make this device an ideal choice for modern smart home applications.
3. Shelly 3EM
The Shelly 3EM distinguishes and detects energy consumption and energy feed-in to the grid. The measurement data is displayed in the app, the optionally activatable cloud, and the web interface in clear graphics. Additionally, MQTT can be activated to register it with a corresponding MQTT broker. It is factory calibrated with the included clamps, achieving an accuracy of over 99%. Furthermore, it features a relay contact that can be used to control a relay, for example. Installation is done in the distribution box on the DIN rail. The measurement values are displayed in real-time. It is also possible to calculate energy costs. The Shelly 3EM can be controlled via the Shelly app, the optionally activatable cloud, as well as through MQTT and REST API. Energy consumption thresholds can be set, and when reached, the Shelly 3EM can switch off the power via the relay contact. Control based on time or sunrise and sunset is also possible. In addition to measuring energy consumption, the energy fed into the grid can also be measured. The Shelly 3EM automatically detects how much energy is consumed and how much is fed in, presenting this information clearly in a graphic. The measurement data is stored in the cloud for 365 days. The data is also written to a CSV file in 5-minute intervals, which can be exported by the Shelly 3EM. The Shelly 3EM features a programming and debug header that can be used for flashing alternative firmware. It is equipped with an ESP8266 with 4 MB of flash. It can be integrated into various smart home systems: Home Assistant, Hubitat, openHAB, Domoticz, REST API, MQTT, ioBroker, nymea, and HomeSeer.
Included in delivery: 1x Shelly 3EM, 1x user manual, 3x current transformers 120A.
4. Shelly Pro 3EM 400A
Shelly Pro 3EM-400 is a three-phase energy meter for DIN rail mounting. Equipped with full gen2 firmware flexibility and LAN connectivity, it offers professional integrators additional options for end customer solutions. It can operate standalone on a local LAN and/or Wi-Fi network or via cloud home automation services via MQTT, HTTP and WebSocket. All incoming connections support TLS. The device reports the cumulative energy as well as the instantaneous voltage, current, active and apparent power per phase in real time. It stores data in non-volatile memory, which can be retrieved at 1-minute intervals for a period of up to 60 days. The device has a real-time clock to maintain the correct time if the connection to an SNTP server is interrupted. Shelly Pro 3EM-400 can be remotely accessed, set up and monitored by the user. The device can also access and communicate with an automation system as long as it is in the same network infrastructure. The device has an integrated web interface that allows you to monitor and control the device and customise its settings. The device does not have a built-in relay. The contactor is controlled via a Shelly Pro add-on, which is connected to the Shelly Pro 3EM-400. Scope of delivery: 3x 400 A current transformers
5. Shelly PRO EM - 50
The Shelly Pro EM-50A is a DIN-mounted single-phase energy meter with an integrated switch for relay control. With an accuracy of 1% in measuring active energy, the Shelly Pro EM-50 can be used to monitor consumption and control various household appliances, circuits, and office equipment. The device features a data history of 60 days in 1-minute intervals. Additionally, its scripting capabilities allow for the execution of complex scenes and provide more comprehensive monitoring options.
6. Shelly 3EM-63T Gen3
The Shelly 3EM-63T Gen3 (Flat Terminal Model) is an advanced three-phase energy meter specifically designed to accurately measure energy consumption in three individual phases. With a maximum load of up to 63A and an accuracy of 99%, this device fulfils IEC 62053-21 Class B standards. It enables real-time monitoring of power data such as current, voltage and power factor with a resolution of one minute. The integrated data storage allows energy consumption data to be stored for up to five years, enabling comprehensive analysis of energy consumption over longer periods of time. The Shelly 3EM-63T is easy to install and requires no additional space on the DIN rail as the electronics and current transformers are integrated in a compact housing. The device also offers broad compatibility with over 200 smart home systems, making it a flexible solution for modern households.
7. Shelly Split Core
Current transformer clamp for Shelly Pro 3 EM. Rated primary current: 120 A. Rated secondary current: 40 mA. Accuracy: 1%. Can measure up to 120 A for each phase and the neutral conductor. Phase sequence error detection (optional). Memory that can be retrieved over a period of up to 60 days in 1-minute intervals. Two-way energy consumption monitoring. Monitor your home, office, or factory to avoid unnecessary expenses or voltage drops that can damage your household and office appliances. Shelly Pro 3 EM can calculate two-way consumption: produced and consumed energy for each of the three phases. The device can also be configured to measure three separate circuits of a single-phase electrical system. Displays the quality of your power grid in terms of active power, reactive power, voltage, and power factor.
8. Shelly Plus PM Mini
The Shelly Plus PM Mini is a compact and powerful energy meter designed for precise monitoring of the energy consumption of electrical devices and lighting systems. With its miniature size, it is the smallest power meter in the world and can be easily installed behind wall switches or outlets. Installation is quick and simple, taking less than 10 minutes, and energy consumption can be monitored from anywhere, thanks to its Wi-Fi connectivity. The Shelly Plus PM Mini is highly compatible with existing smart ecosystems and offers seamless integration into tight spaces where traditional relays do not fit. Despite its small dimensions, it provides all the features of the Plus series and allows for efficient use of available space.
- Maximum current of 16 amps for versatile applications
- Flush mounting allows for discreet installation
- Digital display for clear and precise readings
- Compatible with Danish sockets and other electrical boxes
- Measurement unit in kilowatt-hours for easy consumption analysis.
9. Shelly EM WiFi-Energy Meter incl. 50 A current transformer terminal, type
WLAN power meter with switch output and a 50 A current transformer clamp. Two independent channels for measuring up to 120 A per channel. A switch output of up to 2 A or control of a relay. Memory for one year of local storage of energy measurement data. Voltage measurement and configurable alarm notifications. Control via app, browser, or REST API. Daily and weekly timers or consumption-dependent control. Monitor your energy consumption in real-time. With the Shelly EM, you can measure two circuits with up to 120 A each using two current transformer clamps. Through the app or the cloud, you can view your consumption history and optimize it to save electricity and money. An export function for the data is also available. For developers: The Shelly EM is equipped with a programming/debug header that can be used to flash alternative firmware. It has an ESP8266 with a 4 MB flash chip built-in. Supported platforms include MQTT, ioBroker, Home Assistant, OpenHAB, Domoticz, and REST API. Energy measurement: With the Shelly EM, you can simultaneously measure how much energy your house is consuming and how much energy your solar system is producing.
