Trilux Busbar module

Trilux Power Track Module 7650 3PH L150 05 NO

Manufacturer: Trilux
Description: Black power track module
Type: 7650 3PH L150 05 NO
Number of groups/phases: 3
Nominal voltage: 230 V
Bus capable: no
Shape: rectangular
Material: steel
Surface finish: other
Color: black
Surface-mounted: yes
Recessed: no
Suitable for pendant suspension: yes
Bendable: no
Length: 1474 mm
Width: 81 mm
Height: 49 mm
Protection class: I

The Trilux power track module 7650 3PH L150 05 NO is a device carrier for the E-Line lighting track system 7650Fi. It is a 3-phase power track module designed to accommodate spotlight modules with Euro adapters. It is compatible with E-Line Fix 0765... support profiles in lengths of 1475 mm, 2950 mm, or 4425 mm (connector spacing 1500 mm) in IP20 or IP64.

The module can be used as a standalone or lighting track fixture for direct ceiling mounting as well as suspended mounting using separately ordered accessories. The electrical connection is made automatically when the device carrier is inserted into the support profile. Phase selection is done via a plug terminal. Attachment to the support profile is achieved through tool-free stainless steel snap locks.

The proper installation of the device carrier with the support profile is confirmed by a clicking sound. The transparent mounting elements made of UV-stabilized polycarbonate can be removed after successful installation, providing theft and disassembly protection.

The NORDIC system includes a device carrier made of sheet steel, coated in black, with a length of 1474 mm and a usable rail length of 800 mm. It meets DIN 10500 standards and is suitable for applications in companies certified under HACCP, IFS Version 6, and/or BRC Global Standard Food Version 7 in the food and beverage industry. The spotlights shown in the image are not included in the delivery. E-Line 3-phase power track modules are not suitable for combination with Flex 370 or Fix 37 universal support profiles.

EAN: 4018242433032.
