Name: ZED X Mini 50mm Stereo Camera with Polarisation Filter without Capture Card
Brand: Stereolabs
SKU: 39233001
Price: 949 CHF
Availability: InStock

isSSR

offer

olderThan3MonthTimestamp

path

sectorId

shopArea

slug

tagIds

productDetailPageQuery

productBySlug

alternateLinks

dutchAuctionBannerLazy

alternateLinksByPath

currentAuctionEvent

Zurich

Lausanne

Basel

Kriens

Winterthur

Bern

Dietikon

Geneva

Wohlen

St. Gallen

Stereolabs

The highest level of perception

The new ZED X is an IP66-rated robotic global shutter camera based on the Neural Depth Engine 2. With its robust aluminum housing, powerful IMU, secure GMSL2 connection, and external image synchronization, it is ready for immediate use in the field. In addition, the ZED X has a frame rate of up to 120 fps at 960x600 and a pixel size of 3 m. Capture every movement without sacrificing a hint of dynamic range or image quality thanks to the global shutter. No blurred or curved lines. Just perfect pixels in every scene.

Dimensions

Technical data

Global shutter with 1200p 60 fps
With two 1920x1200 resolution global shutter color sensors, the camera produces crystal clear images that quickly capture any busy environment.

Powerful IMU
The all-new IMU combines a triaxial 16-bit accelerometer and gyroscope with vibration resistance, ultra-low noise, and bias for exceptional motion tracking.

Neural Depth Engine 2
Stereolabs' Neural Depth Engine 2 enables 50% more accurate depth maps and is robust against unstructured surfaces and lighting conditions, from 10 cm to tens of meters.

Secure GMSL2 connection
Ideal for robotics, the GMSL2 output transmits video without EMI to a Jetson Orin over a distance of up to 15 m with low latency via a robust interface.

Industrial grade housing
The rugged IP66 enclosure is perfect for industrial environments. It provides protection against dust and water ingress, which is essential for mobile robots.

Multi-camera synchronization
Hardware synchronization for multiple connected devices at frame level within 100 microseconds. Capture multiple RGB and depth images of the same scene, all aligned with each other.

Attention

The ZED X can only be used with the Capture Card (selectable in the dropdown) or the ZED Box.

Scope of delivery
1x ZED X / X MINI
1x 1.5 m GMSL2 cable.

Actual product image Stereolabs ZED X Mini 50mm Stereo Camera with Polarisation Filter without Capture Card (Camera)
